| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_134T11_9000000870_06501cztM0_level2.evt | modeM0/AS1G06_134T11_9000000870_06501cztM0_level2_quad_clean.evt |
| Size (bytes) | 420,779,520 | 98,199,360 |
| Size | 401.3 MB | 93.7 MB |
| Events in quadrant A | 2,979,655 | 632,937 |
| Events in quadrant B | 3,151,014 | 640,011 |
| Events in quadrant C | 2,828,992 | 628,041 |
| Events in quadrant D | 3,328,834 | 607,054 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13714 | 2 |
| B | 0 | 13984 | 1 |
| C | 0 | 13536 | 1 |
| D | 0 | 14707 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6682 | 96 | 1.436696% |
| B | 6682 | 68 | 1.017659% |
| C | 6682 | 16 | 0.239449% |
| D | 6682 | 118 | 1.765938% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7527 | 6683 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7527 | 6683 | 14 | 14 | 0.19% | 0.21% |  |
| C | 7527 | 6683 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7527 | 6683 | 68 | 68 | 0.90% | 1.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 55364 | 353.31 | 755 | 738 | 154.6 |
| A | 8 | 15 | 13465 | 82.32 | 755 | 738 | 154.6 |
| A | 0 | 226 | 7331 | 42.64 | 755 | 738 | 154.6 |
| B | 4 | 80 | 84831 | 588.2 | 756 | 736 | 143.0 |
| B | 4 | 81 | 64163 | 443.64 | 756 | 736 | 143.0 |
| B | 0 | 228 | 24922 | 169.17 | 756 | 736 | 143.0 |
| C | 13 | 61 | 5918 | 31.3 | 723 | 727 | 165.8 |
| C | 8 | 222 | 2939 | 13.34 | 723 | 727 | 165.8 |
| C | 1 | 16 | 2867 | 12.9 | 723 | 727 | 165.8 |
| D | 2 | 152 | 355124 | 2000.49 | 728 | 705 | 177.2 |
| D | 2 | 136 | 37636 | 208.45 | 728 | 705 | 177.2 |
| D | 13 | 137 | 35058 | 193.9 | 728 | 705 | 177.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
