| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_136T02_9000000876_06511cztM0_level2.evt | modeM0/AS1G06_136T02_9000000876_06511cztM0_level2_quad_clean.evt |
| Size (bytes) | 456,799,680 | 98,421,120 |
| Size | 435.6 MB | 93.9 MB |
| Events in quadrant A | 3,001,687 | 639,369 |
| Events in quadrant B | 3,068,494 | 657,434 |
| Events in quadrant C | 2,961,982 | 642,569 |
| Events in quadrant D | 4,371,816 | 599,225 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13427 | 3 |
| B | 0 | 13484 | 2 |
| C | 0 | 13348 | 2 |
| D | 0 | 17328 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6337 | 20 | 0.315607% |
| B | 6337 | 39 | 0.615433% |
| C | 6337 | 20 | 0.315607% |
| D | 6337 | 86 | 1.357109% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7562 | 6338 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7562 | 6338 | 9 | 9 | 0.12% | 0.14% |  |
| C | 7562 | 6338 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7562 | 6338 | 89 | 89 | 1.18% | 1.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 82884 | 542.19 | 745 | 729 | 151.5 |
| A | 8 | 15 | 49875 | 324.34 | 745 | 729 | 151.5 |
| A | 0 | 226 | 7059 | 41.77 | 745 | 729 | 151.5 |
| B | 4 | 172 | 39770 | 274.27 | 758 | 741 | 142.3 |
| B | 0 | 197 | 22414 | 152.3 | 758 | 741 | 142.3 |
| B | 0 | 219 | 18676 | 126.03 | 758 | 741 | 142.3 |
| C | 4 | 254 | 74778 | 438.3 | 728 | 733 | 168.9 |
| C | 1 | 16 | 40899 | 237.76 | 728 | 733 | 168.9 |
| C | 13 | 61 | 5780 | 29.88 | 728 | 733 | 168.9 |
| D | 2 | 152 | 1446827 | 8272.07 | 713 | 691 | 174.8 |
| D | 2 | 14 | 52188 | 294.57 | 713 | 691 | 174.8 |
| D | 7 | 222 | 42822 | 240.99 | 713 | 691 | 174.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
