| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_246T04_9000000882_06562cztM0_level2.evt | modeM0/AS1G05_246T04_9000000882_06562cztM0_level2_quad_clean.evt |
| Size (bytes) | 570,718,080 | 92,672,640 |
| Size | 544.3 MB | 88.4 MB |
| Events in quadrant A | 3,625,644 | 575,547 |
| Events in quadrant B | 3,788,891 | 583,875 |
| Events in quadrant C | 3,472,381 | 577,623 |
| Events in quadrant D | 5,873,159 | 531,671 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15929 | 2 |
| B | 0 | 16469 | 1 |
| C | 0 | 15889 | 1 |
| D | 0 | 22882 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7726 | 223 | 2.886358% |
| B | 7726 | 279 | 3.611183% |
| C | 7726 | 183 | 2.368625% |
| D | 7726 | 542 | 7.015273% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7831 | 7727 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7831 | 7727 | 37 | 37 | 0.47% | 0.48% |  |
| C | 7831 | 7727 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7831 | 7727 | 244 | 244 | 3.12% | 3.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 102709 | 555.49 | 898 | 877 | 183.3 |
| A | 13 | 251 | 45195 | 241.75 | 898 | 877 | 183.3 |
| A | 14 | 111 | 12786 | 64.96 | 898 | 877 | 183.3 |
| B | 4 | 172 | 84232 | 476.45 | 899 | 875 | 175.0 |
| B | 4 | 48 | 72396 | 408.8 | 899 | 875 | 175.0 |
| B | 0 | 219 | 46287 | 259.56 | 899 | 875 | 175.0 |
| C | 9 | 237 | 61644 | 301.65 | 867 | 868 | 201.5 |
| C | 13 | 61 | 6905 | 29.96 | 867 | 868 | 201.5 |
| C | 8 | 128 | 6086 | 25.9 | 867 | 868 | 201.5 |
| D | 12 | 221 | 1125706 | 5370.23 | 849 | 820 | 209.5 |
| D | 14 | 34 | 1098473 | 5240.22 | 849 | 820 | 209.5 |
| D | 2 | 33 | 247829 | 1179.23 | 849 | 820 | 209.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
