| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_246T04_9000000882_06566cztM0_level2.evt | modeM0/AS1G05_246T04_9000000882_06566cztM0_level2_quad_clean.evt |
| Size (bytes) | 531,630,720 | 72,397,440 |
| Size | 507.0 MB | 69.0 MB |
| Events in quadrant A | 3,047,846 | 437,385 |
| Events in quadrant B | 3,386,393 | 441,244 |
| Events in quadrant C | 3,003,623 | 440,603 |
| Events in quadrant D | 6,211,511 | 408,911 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13655 | 3 |
| B | 0 | 14502 | 2 |
| C | 0 | 13605 | 2 |
| D | 0 | 23029 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6651 | 45 | 0.676590% |
| B | 6651 | 81 | 1.217862% |
| C | 6651 | 34 | 0.511201% |
| D | 6651 | 359 | 5.397685% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7636 | 6652 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7636 | 6652 | 21 | 21 | 0.28% | 0.32% |  |
| C | 7636 | 6652 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7636 | 6652 | 180 | 180 | 2.36% | 2.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 12051 | 70.06 | 784 | 766 | 161.1 |
| A | 14 | 111 | 8865 | 50.28 | 784 | 766 | 161.1 |
| A | 0 | 226 | 7864 | 44.07 | 784 | 766 | 161.1 |
| B | 4 | 81 | 64184 | 417.13 | 789 | 772 | 152.0 |
| B | 0 | 219 | 54555 | 353.79 | 789 | 772 | 152.0 |
| B | 4 | 80 | 38296 | 246.84 | 789 | 772 | 152.0 |
| C | 13 | 61 | 5961 | 29.01 | 767 | 769 | 179.0 |
| C | 9 | 237 | 4459 | 20.62 | 767 | 769 | 179.0 |
| C | 1 | 16 | 3048 | 12.73 | 767 | 769 | 179.0 |
| D | 12 | 221 | 2262549 | 12180.77 | 750 | 725 | 185.7 |
| D | 2 | 33 | 447506 | 2406.08 | 750 | 725 | 185.7 |
| D | 14 | 34 | 344973 | 1853.9 | 750 | 725 | 185.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
