| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_174T04_9000000938_06833cztM0_level2.evt | modeM0/AS1A02_174T04_9000000938_06833cztM0_level2_quad_clean.evt |
| Size (bytes) | 466,902,720 | 78,816,960 |
| Size | 445.3 MB | 75.2 MB |
| Events in quadrant A | 2,942,233 | 490,901 |
| Events in quadrant B | 3,086,660 | 501,377 |
| Events in quadrant C | 3,062,514 | 498,049 |
| Events in quadrant D | 4,638,158 | 474,082 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12818 | 2 |
| B | 0 | 13203 | 1 |
| C | 0 | 12827 | 1 |
| D | 0 | 18176 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6044 | 40 | 0.661813% |
| B | 6044 | 91 | 1.505625% |
| C | 6044 | 62 | 1.025811% |
| D | 6044 | 326 | 5.393779% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7244 | 6045 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7244 | 6045 | 8 | 8 | 0.11% | 0.13% |  |
| C | 7244 | 6045 | 5 | 5 | 0.07% | 0.08% |  |
| D | 7244 | 6045 | 213 | 213 | 2.94% | 3.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 53213 | 348.21 | 738 | 722 | 150.7 |
| A | 0 | 23 | 30770 | 199.33 | 738 | 722 | 150.7 |
| A | 0 | 226 | 9463 | 57.98 | 738 | 722 | 150.7 |
| B | 0 | 219 | 60188 | 421.87 | 748 | 730 | 140.9 |
| B | 0 | 214 | 49394 | 345.28 | 748 | 730 | 140.9 |
| B | 0 | 228 | 45540 | 317.94 | 748 | 730 | 140.9 |
| C | 9 | 247 | 154493 | 912.43 | 728 | 734 | 168.5 |
| C | 12 | 16 | 57293 | 335.63 | 728 | 734 | 168.5 |
| C | 13 | 61 | 5659 | 29.23 | 728 | 734 | 168.5 |
| D | 8 | 195 | 748033 | 4274.62 | 713 | 693 | 174.8 |
| D | 2 | 33 | 465569 | 2658.99 | 713 | 693 | 174.8 |
| D | 2 | 216 | 287342 | 1639.57 | 713 | 693 | 174.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
