| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_174T04_9000000938_06836cztM0_level2.evt | modeM0/AS1A02_174T04_9000000938_06836cztM0_level2_quad_clean.evt |
| Size (bytes) | 644,054,400 | 101,134,080 |
| Size | 614.2 MB | 96.4 MB |
| Events in quadrant A | 4,067,164 | 620,947 |
| Events in quadrant B | 4,238,091 | 632,664 |
| Events in quadrant C | 4,506,832 | 624,409 |
| Events in quadrant D | 6,116,346 | 593,510 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18004 | 4 |
| B | 0 | 18466 | 3 |
| C | 0 | 19056 | 3 |
| D | 0 | 24347 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8513 | 137 | 1.609303% |
| B | 8513 | 224 | 2.631270% |
| C | 8513 | 114 | 1.339128% |
| D | 8513 | 394 | 4.628216% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8893 | 8517 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8893 | 8517 | 8 | 8 | 0.09% | 0.09% |  |
| C | 8893 | 8517 | 2 | 2 | 0.02% | 0.02% |  |
| D | 8893 | 8516 | 168 | 168 | 1.89% | 1.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 44965 | 206.39 | 1040 | 1016 | 212.9 |
| A | 8 | 15 | 13981 | 60.88 | 1040 | 1016 | 212.9 |
| A | 0 | 226 | 10235 | 43.29 | 1040 | 1016 | 212.9 |
| B | 0 | 219 | 49780 | 240.06 | 1052 | 1025 | 203.1 |
| B | 4 | 81 | 41204 | 197.83 | 1052 | 1025 | 203.1 |
| B | 12 | 111 | 20622 | 96.49 | 1052 | 1025 | 203.1 |
| C | 9 | 68 | 260251 | 1085.83 | 1015 | 1021 | 238.7 |
| C | 9 | 247 | 232394 | 969.15 | 1015 | 1021 | 238.7 |
| C | 9 | 16 | 17734 | 70.01 | 1015 | 1021 | 238.7 |
| D | 8 | 195 | 1369199 | 5589.26 | 977 | 944 | 244.8 |
| D | 2 | 33 | 486136 | 1981.99 | 977 | 944 | 244.8 |
| D | 2 | 216 | 303208 | 1234.73 | 977 | 944 | 244.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
