| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_174T04_9000000938_06840cztM0_level2.evt | modeM0/AS1A02_174T04_9000000938_06840cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,675,961,280 | 300,222,720 |
| Size | 1.6 GB | 286.3 MB |
| Events in quadrant A | 11,163,788 | 1,854,748 |
| Events in quadrant B | 11,429,263 | 1,890,482 |
| Events in quadrant C | 12,384,741 | 1,859,471 |
| Events in quadrant D | 14,108,076 | 1,787,664 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 50680 | 5 |
| B | 0 | 51033 | 4 |
| C | 0 | 53876 | 4 |
| D | 0 | 57904 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 504 | 0 |
| B | 0 | 504 | 0 |
| C | 0 | 504 | 0 |
| D | 0 | 504 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 24716 | 188 | 0.760641% |
| B | 24716 | 260 | 1.051950% |
| C | 24716 | 314 | 1.270432% |
| D | 24716 | 434 | 1.755948% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 26846 | 24720 | 5 | 5 | 0.02% | 0.02% |  |
| B | 26846 | 24720 | 11 | 11 | 0.04% | 0.04% |  |
| C | 26846 | 24720 | 158 | 158 | 0.59% | 0.64% |  |
| D | 26846 | 24720 | 174 | 174 | 0.65% | 0.70% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 45616 | 73.56 | 2862 | 2796 | 582.1 |
| A | 15 | 239 | 36738 | 58.31 | 2862 | 2796 | 582.1 |
| A | 14 | 111 | 36456 | 57.83 | 2862 | 2796 | 582.1 |
| B | 0 | 219 | 85870 | 151.27 | 2879 | 2804 | 549.1 |
| B | 12 | 111 | 58783 | 101.94 | 2879 | 2804 | 549.1 |
| B | 11 | 111 | 46562 | 79.69 | 2879 | 2804 | 549.1 |
| C | 9 | 68 | 1030983 | 1591.71 | 2771 | 2783 | 646.0 |
| C | 9 | 247 | 337188 | 517.68 | 2771 | 2783 | 646.0 |
| C | 10 | 22 | 142499 | 216.29 | 2771 | 2783 | 646.0 |
| D | 8 | 195 | 2150529 | 3167.05 | 2763 | 2677 | 678.2 |
| D | 2 | 33 | 556294 | 816.32 | 2763 | 2677 | 678.2 |
| D | 2 | 136 | 391670 | 573.58 | 2763 | 2677 | 678.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
