| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_005T01_9000000948_06891cztM0_level2.evt | modeM0/AS1A02_005T01_9000000948_06891cztM0_level2_quad_clean.evt |
| Size (bytes) | 424,771,200 | 77,644,800 |
| Size | 405.1 MB | 74.0 MB |
| Events in quadrant A | 3,075,882 | 479,251 |
| Events in quadrant B | 3,239,195 | 485,122 |
| Events in quadrant C | 3,083,190 | 483,831 |
| Events in quadrant D | 3,040,944 | 466,766 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13272 | 3 |
| B | 0 | 13685 | 2 |
| C | 0 | 13110 | 2 |
| D | 0 | 13240 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6253 | 46 | 0.735647% |
| B | 6253 | 74 | 1.183432% |
| C | 6253 | 41 | 0.655685% |
| D | 6253 | 46 | 0.735647% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7453 | 6254 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7453 | 6254 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7453 | 6254 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7453 | 6254 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 49232 | 309.38 | 777 | 761 | 156.7 |
| A | 13 | 248 | 20857 | 128.27 | 777 | 761 | 156.7 |
| A | 13 | 14 | 14197 | 85.76 | 777 | 761 | 156.7 |
| B | 4 | 48 | 92733 | 622.83 | 781 | 763 | 147.7 |
| B | 15 | 204 | 29162 | 192.32 | 781 | 763 | 147.7 |
| B | 0 | 214 | 22833 | 149.46 | 781 | 763 | 147.7 |
| C | 9 | 247 | 96563 | 540.97 | 764 | 767 | 177.1 |
| C | 13 | 61 | 6192 | 30.64 | 764 | 767 | 177.1 |
| C | 9 | 54 | 4956 | 23.66 | 764 | 767 | 177.1 |
| D | 12 | 6 | 48816 | 257.02 | 766 | 743 | 187.0 |
| D | 8 | 195 | 39993 | 209.85 | 766 | 743 | 187.0 |
| D | 5 | 81 | 24645 | 127.79 | 766 | 743 | 187.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
