| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_005T01_9000000948_06906cztM0_level2.evt | modeM0/AS1A02_005T01_9000000948_06906cztM0_level2_quad_clean.evt |
| Size (bytes) | 455,391,360 | 84,386,880 |
| Size | 434.3 MB | 80.5 MB |
| Events in quadrant A | 3,153,673 | 526,236 |
| Events in quadrant B | 3,367,571 | 531,336 |
| Events in quadrant C | 3,118,603 | 529,822 |
| Events in quadrant D | 3,704,517 | 509,094 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13697 | 3 |
| B | 0 | 14380 | 2 |
| C | 0 | 13597 | 2 |
| D | 0 | 15523 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6587 | 36 | 0.546531% |
| B | 6587 | 76 | 1.153788% |
| C | 6587 | 29 | 0.440261% |
| D | 6587 | 142 | 2.155761% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7627 | 6588 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7627 | 6588 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7627 | 6588 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7627 | 6588 | 69 | 69 | 0.90% | 1.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 33088 | 197.99 | 798 | 781 | 163.2 |
| A | 0 | 23 | 19690 | 115.88 | 798 | 781 | 163.2 |
| A | 13 | 14 | 19160 | 112.63 | 798 | 781 | 163.2 |
| B | 4 | 81 | 52515 | 341.97 | 802 | 786 | 151.3 |
| B | 0 | 228 | 51727 | 336.76 | 802 | 786 | 151.3 |
| B | 4 | 173 | 47823 | 310.95 | 802 | 786 | 151.3 |
| C | 9 | 247 | 54941 | 299.15 | 783 | 788 | 181.0 |
| C | 13 | 61 | 6120 | 29.45 | 783 | 788 | 181.0 |
| C | 12 | 4 | 3556 | 15.29 | 783 | 788 | 181.0 |
| D | 2 | 216 | 232515 | 1238.09 | 775 | 753 | 187.2 |
| D | 2 | 136 | 105659 | 560.41 | 775 | 753 | 187.2 |
| D | 2 | 152 | 94689 | 501.81 | 775 | 753 | 187.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
