| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_090T02_9000000956_06963cztM0_level2.evt | modeM0/AS1A02_090T02_9000000956_06963cztM0_level2_quad_clean.evt |
| Size (bytes) | 469,123,200 | 64,477,440 |
| Size | 447.4 MB | 61.5 MB |
| Events in quadrant A | 3,272,931 | 374,434 |
| Events in quadrant B | 3,302,479 | 379,267 |
| Events in quadrant C | 3,238,390 | 380,622 |
| Events in quadrant D | 3,948,236 | 360,429 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13773 | 2 |
| B | 0 | 13789 | 1 |
| C | 0 | 13792 | 1 |
| D | 0 | 16020 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6563 | 95 | 1.447509% |
| B | 6563 | 92 | 1.401798% |
| C | 6563 | 71 | 1.081822% |
| D | 6563 | 95 | 1.447509% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7793 | 6564 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7793 | 6564 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7793 | 6564 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7793 | 6564 | 4 | 4 | 0.05% | 0.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 30344 | 171.0 | 841 | 824 | 172.6 |
| A | 0 | 226 | 8192 | 42.68 | 841 | 824 | 172.6 |
| A | 12 | 194 | 7827 | 40.57 | 841 | 824 | 172.6 |
| B | 0 | 187 | 15988 | 95.32 | 836 | 817 | 159.2 |
| B | 12 | 111 | 15295 | 90.97 | 836 | 817 | 159.2 |
| B | 11 | 111 | 12564 | 73.81 | 836 | 817 | 159.2 |
| C | 7 | 247 | 47233 | 246.7 | 816 | 820 | 188.1 |
| C | 13 | 61 | 6472 | 30.04 | 816 | 820 | 188.1 |
| C | 12 | 4 | 4156 | 17.73 | 816 | 820 | 188.1 |
| D | 8 | 195 | 519300 | 2547.62 | 821 | 795 | 203.5 |
| D | 1 | 20 | 179962 | 880.32 | 821 | 795 | 203.5 |
| D | 2 | 136 | 63865 | 309.89 | 821 | 795 | 203.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
