| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_151T01_9000000960_06988cztM0_level2.evt | modeM0/AS1T01_151T01_9000000960_06988cztM0_level2_quad_clean.evt |
| Size (bytes) | 422,352,000 | 62,020,800 |
| Size | 402.8 MB | 59.1 MB |
| Events in quadrant A | 2,939,429 | 364,118 |
| Events in quadrant B | 3,228,622 | 359,198 |
| Events in quadrant C | 2,886,827 | 361,803 |
| Events in quadrant D | 3,305,134 | 350,551 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12911 | 2 |
| B | 0 | 13684 | 1 |
| C | 0 | 12883 | 1 |
| D | 0 | 13718 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6330 | 35 | 0.552923% |
| B | 6330 | 117 | 1.848341% |
| C | 6330 | 22 | 0.347551% |
| D | 6330 | 60 | 0.947867% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7485 | 6331 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7485 | 6331 | 57 | 57 | 0.76% | 0.90% |  |
| C | 7485 | 6331 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7485 | 6331 | 40 | 40 | 0.53% | 0.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 14 | 9117 | 54.31 | 758 | 742 | 154.2 |
| A | 14 | 239 | 7735 | 45.35 | 758 | 742 | 154.2 |
| A | 0 | 226 | 7017 | 40.69 | 758 | 742 | 154.2 |
| B | 0 | 228 | 233543 | 1598.94 | 760 | 743 | 145.6 |
| B | 0 | 219 | 18124 | 119.38 | 760 | 743 | 145.6 |
| B | 12 | 111 | 14601 | 95.18 | 760 | 743 | 145.6 |
| C | 13 | 61 | 5913 | 30.22 | 738 | 743 | 171.1 |
| C | 12 | 4 | 4184 | 20.11 | 738 | 743 | 171.1 |
| C | 1 | 16 | 2051 | 7.65 | 738 | 743 | 171.1 |
| D | 8 | 195 | 312792 | 1720.24 | 736 | 713 | 181.4 |
| D | 14 | 34 | 88730 | 485.17 | 736 | 713 | 181.4 |
| D | 13 | 169 | 58206 | 316.91 | 736 | 713 | 181.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
