| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_164T01_9000000968_07079cztM0_level2.evt | modeM0/AS1G06_164T01_9000000968_07079cztM0_level2_quad_clean.evt |
| Size (bytes) | 410,526,720 | 81,950,400 |
| Size | 391.5 MB | 78.2 MB |
| Events in quadrant A | 2,783,465 | 527,845 |
| Events in quadrant B | 3,089,328 | 535,193 |
| Events in quadrant C | 2,678,547 | 511,345 |
| Events in quadrant D | 3,472,961 | 487,726 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12341 | 2 |
| B | 0 | 13024 | 1 |
| C | 0 | 12251 | 1 |
| D | 0 | 14556 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5996 | 113 | 1.884590% |
| B | 5996 | 142 | 2.368245% |
| C | 5996 | 76 | 1.267512% |
| D | 5996 | 268 | 4.469646% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7106 | 5997 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7106 | 5997 | 23 | 23 | 0.32% | 0.38% |  |
| C | 7106 | 5997 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7106 | 5997 | 160 | 160 | 2.25% | 2.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 34062 | 229.15 | 713 | 696 | 145.6 |
| A | 0 | 226 | 6944 | 42.91 | 713 | 696 | 145.6 |
| A | 12 | 194 | 6591 | 40.49 | 713 | 696 | 145.6 |
| B | 0 | 219 | 232217 | 1707.55 | 712 | 694 | 135.6 |
| B | 0 | 214 | 88422 | 647.02 | 712 | 694 | 135.6 |
| B | 12 | 111 | 13196 | 92.21 | 712 | 694 | 135.6 |
| C | 9 | 68 | 8798 | 52.16 | 682 | 683 | 155.6 |
| C | 13 | 61 | 5392 | 30.27 | 682 | 683 | 155.6 |
| C | 10 | 22 | 3631 | 18.95 | 682 | 683 | 155.6 |
| D | 1 | 83 | 465501 | 2807.3 | 678 | 657 | 165.6 |
| D | 9 | 68 | 206891 | 1245.5 | 678 | 657 | 165.6 |
| D | 2 | 136 | 70739 | 423.24 | 678 | 657 | 165.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
