| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_090T01_9000000970_07118cztM0_level2.evt | modeM0/AS1A02_090T01_9000000970_07118cztM0_level2_quad_clean.evt |
| Size (bytes) | 408,136,320 | 83,404,800 |
| Size | 389.2 MB | 79.5 MB |
| Events in quadrant A | 2,797,608 | 534,159 |
| Events in quadrant B | 3,059,222 | 543,203 |
| Events in quadrant C | 2,801,471 | 532,567 |
| Events in quadrant D | 3,295,153 | 497,664 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12344 | 2 |
| B | 0 | 13127 | 1 |
| C | 0 | 12294 | 1 |
| D | 0 | 13904 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5984 | 19 | 0.317513% |
| B | 5984 | 37 | 0.618316% |
| C | 5984 | 12 | 0.200535% |
| D | 5984 | 64 | 1.069519% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7094 | 5985 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7094 | 5984 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7094 | 5985 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7094 | 5985 | 41 | 41 | 0.58% | 0.69% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 25133 | 167.92 | 711 | 699 | 145.5 |
| A | 14 | 238 | 18906 | 125.12 | 711 | 699 | 145.5 |
| A | 8 | 15 | 11598 | 74.9 | 711 | 699 | 145.5 |
| B | 0 | 219 | 105578 | 763.11 | 722 | 706 | 137.4 |
| B | 0 | 214 | 58602 | 421.28 | 722 | 706 | 137.4 |
| B | 3 | 220 | 36372 | 259.53 | 722 | 706 | 137.4 |
| C | 4 | 254 | 55968 | 339.48 | 698 | 703 | 162.8 |
| C | 8 | 128 | 11278 | 64.96 | 698 | 703 | 162.8 |
| C | 8 | 112 | 5525 | 29.62 | 698 | 703 | 162.8 |
| D | 2 | 216 | 353311 | 2044.14 | 690 | 668 | 172.5 |
| D | 8 | 195 | 268746 | 1553.95 | 690 | 668 | 172.5 |
| D | 2 | 14 | 26843 | 151.73 | 690 | 668 | 172.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
