| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_051T01_9000000972_07139cztM0_level2.evt | modeM0/AS1G06_051T01_9000000972_07139cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,536,000 | 77,886,720 |
| Size | 476.4 MB | 74.3 MB |
| Events in quadrant A | 3,349,483 | 466,324 |
| Events in quadrant B | 3,518,943 | 477,009 |
| Events in quadrant C | 3,324,535 | 468,440 |
| Events in quadrant D | 4,448,715 | 447,467 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14794 | 2 |
| B | 0 | 14969 | 1 |
| C | 0 | 14865 | 1 |
| D | 0 | 18216 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7160 | 202 | 2.821229% |
| B | 7160 | 198 | 2.765363% |
| C | 7160 | 197 | 2.751397% |
| D | 7160 | 339 | 4.734637% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7450 | 7160 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7450 | 7160 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7450 | 7160 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7450 | 7160 | 132 | 132 | 1.77% | 1.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 25767 | 140.5 | 860 | 836 | 177.4 |
| A | 15 | 234 | 8273 | 41.91 | 860 | 836 | 177.4 |
| A | 0 | 226 | 8177 | 41.37 | 860 | 836 | 177.4 |
| B | 0 | 219 | 82467 | 482.84 | 863 | 840 | 169.1 |
| B | 0 | 214 | 75012 | 438.74 | 863 | 840 | 169.1 |
| B | 12 | 111 | 17473 | 98.39 | 863 | 840 | 169.1 |
| C | 4 | 254 | 22381 | 108.85 | 835 | 839 | 197.9 |
| C | 8 | 128 | 14572 | 69.39 | 835 | 839 | 197.9 |
| C | 9 | 15 | 8040 | 36.39 | 835 | 839 | 197.9 |
| D | 2 | 216 | 713269 | 3418.21 | 836 | 811 | 208.4 |
| D | 12 | 233 | 401056 | 1920.28 | 836 | 811 | 208.4 |
| D | 14 | 34 | 72979 | 346.25 | 836 | 811 | 208.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
