| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_029T02_9000000974_07155cztM0_level2.evt | modeM0/AS1G06_029T02_9000000974_07155cztM0_level2_quad_clean.evt |
| Size (bytes) | 609,134,400 | 82,670,400 |
| Size | 580.9 MB | 78.8 MB |
| Events in quadrant A | 3,860,486 | 488,817 |
| Events in quadrant B | 4,221,370 | 498,963 |
| Events in quadrant C | 3,797,789 | 493,836 |
| Events in quadrant D | 6,023,400 | 463,344 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16951 | 4 |
| B | 0 | 17839 | 3 |
| C | 0 | 16988 | 3 |
| D | 0 | 23173 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8027 | 312 | 3.886882% |
| B | 8027 | 346 | 4.310452% |
| C | 8027 | 284 | 3.538059% |
| D | 8027 | 773 | 9.629999% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8382 | 8028 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8382 | 8028 | 8 | 8 | 0.10% | 0.10% |  |
| C | 8382 | 8029 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8382 | 8028 | 334 | 334 | 3.98% | 4.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 112 | 15970 | 73.26 | 993 | 967 | 204.8 |
| A | 0 | 226 | 9475 | 41.55 | 993 | 967 | 204.8 |
| A | 8 | 15 | 9221 | 40.31 | 993 | 967 | 204.8 |
| B | 0 | 214 | 168070 | 857.45 | 993 | 965 | 194.9 |
| B | 4 | 80 | 89318 | 453.35 | 993 | 965 | 194.9 |
| B | 4 | 81 | 53887 | 271.55 | 993 | 965 | 194.9 |
| C | 4 | 254 | 16624 | 68.57 | 966 | 971 | 228.3 |
| C | 10 | 22 | 10116 | 40.06 | 966 | 971 | 228.3 |
| C | 13 | 61 | 7402 | 28.17 | 966 | 971 | 228.3 |
| D | 2 | 216 | 1622189 | 6903.27 | 949 | 916 | 234.9 |
| D | 8 | 195 | 394865 | 1677.41 | 949 | 916 | 234.9 |
| D | 12 | 233 | 181491 | 768.88 | 949 | 916 | 234.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
