| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_083T01_9000000984_07211cztM0_level2.evt | modeM0/AS1G06_083T01_9000000984_07211cztM0_level2_quad_clean.evt |
| Size (bytes) | 471,274,560 | 104,846,400 |
| Size | 449.4 MB | 100.0 MB |
| Events in quadrant A | 3,154,184 | 680,028 |
| Events in quadrant B | 3,253,218 | 695,304 |
| Events in quadrant C | 3,417,995 | 674,129 |
| Events in quadrant D | 3,975,081 | 641,924 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14353 | 2 |
| B | 0 | 14372 | 1 |
| C | 0 | 15173 | 1 |
| D | 0 | 16450 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6947 | 113 | 1.626601% |
| B | 6947 | 81 | 1.165971% |
| C | 6947 | 145 | 2.087232% |
| D | 6947 | 159 | 2.288758% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7382 | 6947 | 20 | 20 | 0.27% | 0.29% |  |
| B | 7382 | 6948 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7382 | 6947 | 60 | 60 | 0.81% | 0.86% |  |
| D | 7382 | 6947 | 59 | 59 | 0.80% | 0.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 77469 | 478.53 | 789 | 768 | 160.3 |
| A | 15 | 174 | 12576 | 73.67 | 789 | 768 | 160.3 |
| A | 14 | 111 | 8647 | 49.16 | 789 | 768 | 160.3 |
| B | 0 | 214 | 76938 | 505.95 | 798 | 780 | 150.5 |
| B | 4 | 81 | 45363 | 296.18 | 798 | 780 | 150.5 |
| B | 15 | 204 | 15602 | 98.47 | 798 | 780 | 150.5 |
| C | 9 | 243 | 388107 | 2145.43 | 776 | 777 | 180.5 |
| C | 13 | 61 | 5873 | 28.23 | 776 | 777 | 180.5 |
| C | 12 | 4 | 2851 | 11.49 | 776 | 777 | 180.5 |
| D | 8 | 195 | 402917 | 2130.56 | 770 | 745 | 188.8 |
| D | 2 | 216 | 321223 | 1697.77 | 770 | 745 | 188.8 |
| D | 14 | 34 | 128983 | 679.36 | 770 | 745 | 188.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
