| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_246T03_9000000990_07252cztM0_level2.evt | modeM0/AS1G05_246T03_9000000990_07252cztM0_level2_quad_clean.evt |
| Size (bytes) | 442,681,920 | 101,249,280 |
| Size | 422.2 MB | 96.6 MB |
| Events in quadrant A | 2,983,392 | 654,092 |
| Events in quadrant B | 3,242,654 | 676,273 |
| Events in quadrant C | 2,991,316 | 661,861 |
| Events in quadrant D | 3,743,936 | 617,530 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13409 | 3 |
| B | 0 | 14059 | 2 |
| C | 0 | 13467 | 2 |
| D | 0 | 16041 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6546 | 10 | 0.152765% |
| B | 6546 | 30 | 0.458295% |
| C | 6546 | 8 | 0.122212% |
| D | 6546 | 157 | 2.398411% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7906 | 6547 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7906 | 6547 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7906 | 6547 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7906 | 6547 | 122 | 122 | 1.54% | 1.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 17330 | 105.63 | 770 | 756 | 156.9 |
| A | 0 | 226 | 7362 | 42.1 | 770 | 756 | 156.9 |
| A | 12 | 194 | 6675 | 37.72 | 770 | 756 | 156.9 |
| B | 10 | 245 | 72825 | 490.6 | 785 | 768 | 146.9 |
| B | 0 | 214 | 47681 | 319.41 | 785 | 768 | 146.9 |
| B | 4 | 239 | 29978 | 198.88 | 785 | 768 | 146.9 |
| C | 9 | 68 | 22989 | 127.02 | 754 | 759 | 175.0 |
| C | 9 | 243 | 20373 | 112.07 | 754 | 759 | 175.0 |
| C | 13 | 61 | 5843 | 29.05 | 754 | 759 | 175.0 |
| D | 12 | 233 | 377727 | 2087.63 | 737 | 714 | 180.6 |
| D | 2 | 14 | 250389 | 1382.52 | 737 | 714 | 180.6 |
| D | 2 | 216 | 192568 | 1062.35 | 737 | 714 | 180.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
