| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_150T04_9000001022_07423cztM0_level2.evt | modeM0/AS1A02_150T04_9000001022_07423cztM0_level2_quad_clean.evt |
| Size (bytes) | 268,508,160 | 45,984,960 |
| Size | 256.1 MB | 43.9 MB |
| Events in quadrant A | 1,875,690 | 282,159 |
| Events in quadrant B | 1,839,348 | 286,524 |
| Events in quadrant C | 2,139,748 | 286,977 |
| Events in quadrant D | 2,025,895 | 276,402 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 76 | 0 |
| B | 0 | 76 | 0 |
| C | 0 | 76 | 0 |
| D | 0 | 76 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8096 | 2 |
| B | 0 | 7917 | 1 |
| C | 0 | 8747 | 1 |
| D | 0 | 8643 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3671 | 74 | 2.015800% |
| B | 3671 | 48 | 1.307546% |
| C | 3671 | 42 | 1.144102% |
| D | 3671 | 87 | 2.369926% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4886 | 3672 | 18 | 18 | 0.37% | 0.49% |  |
| B | 4886 | 3672 | 1 | 1 | 0.02% | 0.03% |  |
| C | 4886 | 3672 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4886 | 3672 | 44 | 44 | 0.90% | 1.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 234 | 84946 | 893.64 | 463 | 454 | 94.5 |
| A | 3 | 1 | 6090 | 59.61 | 463 | 454 | 94.5 |
| A | 0 | 226 | 4330 | 41.0 | 463 | 454 | 94.5 |
| B | 4 | 170 | 10621 | 111.87 | 469 | 458 | 90.8 |
| B | 12 | 111 | 8861 | 92.49 | 469 | 458 | 90.8 |
| B | 11 | 111 | 7067 | 72.75 | 469 | 458 | 90.8 |
| C | 9 | 68 | 346093 | 3228.86 | 459 | 462 | 107.0 |
| C | 13 | 61 | 3621 | 29.51 | 459 | 462 | 107.0 |
| C | 14 | 67 | 1862 | 13.08 | 459 | 462 | 107.0 |
| D | 2 | 14 | 165305 | 1464.86 | 456 | 444 | 112.5 |
| D | 8 | 195 | 43086 | 378.89 | 456 | 444 | 112.5 |
| D | 2 | 216 | 30000 | 262.62 | 456 | 444 | 112.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
