| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_108T01_9000001024_07442cztM0_level2.evt | modeM0/AS1A02_108T01_9000001024_07442cztM0_level2_quad_clean.evt |
| Size (bytes) | 456,036,480 | 96,877,440 |
| Size | 434.9 MB | 92.4 MB |
| Events in quadrant A | 3,281,353 | 615,622 |
| Events in quadrant B | 3,415,991 | 627,881 |
| Events in quadrant C | 3,366,833 | 611,928 |
| Events in quadrant D | 3,265,754 | 585,665 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14706 | 4 |
| B | 0 | 15029 | 3 |
| C | 0 | 14748 | 3 |
| D | 0 | 14923 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7066 | 80 | 1.132182% |
| B | 7066 | 114 | 1.613360% |
| C | 7066 | 44 | 0.622700% |
| D | 7066 | 50 | 0.707614% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9071 | 7069 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9071 | 7069 | 1 | 1 | 0.01% | 0.01% |  |
| C | 9071 | 7069 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9071 | 7069 | 14 | 14 | 0.15% | 0.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 18351 | 102.12 | 843 | 825 | 171.6 |
| A | 8 | 15 | 10234 | 54.83 | 843 | 825 | 171.6 |
| A | 3 | 1 | 8737 | 46.1 | 843 | 825 | 171.6 |
| B | 0 | 214 | 74889 | 456.24 | 854 | 835 | 162.3 |
| B | 12 | 111 | 16646 | 97.41 | 854 | 835 | 162.3 |
| B | 4 | 81 | 14682 | 85.31 | 854 | 835 | 162.3 |
| C | 9 | 68 | 136892 | 711.35 | 822 | 827 | 191.3 |
| C | 4 | 238 | 8552 | 40.39 | 822 | 827 | 191.3 |
| C | 13 | 61 | 6287 | 28.55 | 822 | 827 | 191.3 |
| D | 2 | 14 | 96833 | 483.57 | 813 | 788 | 198.6 |
| D | 5 | 233 | 40927 | 202.09 | 813 | 788 | 198.6 |
| D | 14 | 34 | 18469 | 89.02 | 813 | 788 | 198.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
