| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_134T01_9000001036_07514cztM0_level2.evt | modeM0/AS1A02_134T01_9000001036_07514cztM0_level2_quad_clean.evt |
| Size (bytes) | 491,693,760 | 99,601,920 |
| Size | 468.9 MB | 95.0 MB |
| Events in quadrant A | 2,964,255 | 655,062 |
| Events in quadrant B | 3,100,778 | 661,277 |
| Events in quadrant C | 5,263,348 | 629,168 |
| Events in quadrant D | 3,119,977 | 615,891 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13273 | 3 |
| B | 0 | 13555 | 2 |
| C | 0 | 20174 | 2 |
| D | 0 | 14000 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6525 | 18 | 0.275862% |
| B | 6525 | 17 | 0.260536% |
| C | 6525 | 72 | 1.103448% |
| D | 6525 | 48 | 0.735632% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7536 | 6527 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7536 | 6527 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7536 | 6527 | 35 | 35 | 0.46% | 0.54% |  |
| D | 7536 | 6527 | 36 | 36 | 0.48% | 0.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 14 | 18578 | 115.1 | 763 | 748 | 154.9 |
| A | 2 | 79 | 8955 | 52.98 | 763 | 748 | 154.9 |
| A | 0 | 226 | 7284 | 42.19 | 763 | 748 | 154.9 |
| B | 0 | 214 | 79592 | 544.56 | 768 | 749 | 144.8 |
| B | 0 | 219 | 20773 | 138.3 | 768 | 749 | 144.8 |
| B | 12 | 111 | 14110 | 92.28 | 768 | 749 | 144.8 |
| C | 9 | 68 | 2385995 | 14262.43 | 731 | 736 | 167.2 |
| C | 8 | 229 | 15354 | 87.41 | 731 | 736 | 167.2 |
| C | 13 | 61 | 5724 | 29.83 | 731 | 736 | 167.2 |
| D | 12 | 233 | 86628 | 481.83 | 730 | 707 | 178.3 |
| D | 2 | 152 | 70521 | 391.5 | 730 | 707 | 178.3 |
| D | 2 | 136 | 70225 | 389.84 | 730 | 707 | 178.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
