| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_076T01_9000001038_07541cztM0_level2.evt | modeM0/AS1G06_076T01_9000001038_07541cztM0_level2_quad_clean.evt |
| Size (bytes) | 455,734,080 | 69,330,240 |
| Size | 434.6 MB | 66.1 MB |
| Events in quadrant A | 3,236,197 | 420,639 |
| Events in quadrant B | 3,324,448 | 426,332 |
| Events in quadrant C | 3,159,765 | 411,357 |
| Events in quadrant D | 3,643,348 | 391,055 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13681 | 3 |
| B | 0 | 13880 | 2 |
| C | 0 | 13578 | 2 |
| D | 0 | 15135 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6449 | 132 | 2.046829% |
| B | 6449 | 137 | 2.124360% |
| C | 6449 | 99 | 1.535122% |
| D | 6449 | 211 | 3.271825% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7704 | 6449 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7704 | 6449 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7704 | 6449 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7704 | 6449 | 85 | 85 | 1.10% | 1.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 14 | 16395 | 92.59 | 836 | 819 | 168.2 |
| A | 0 | 226 | 7983 | 42.58 | 836 | 819 | 168.2 |
| A | 12 | 194 | 7545 | 39.98 | 836 | 819 | 168.2 |
| B | 4 | 173 | 21910 | 135.45 | 835 | 817 | 155.7 |
| B | 0 | 214 | 18196 | 111.6 | 835 | 817 | 155.7 |
| B | 4 | 239 | 17236 | 105.43 | 835 | 817 | 155.7 |
| C | 8 | 229 | 15435 | 79.89 | 803 | 807 | 183.1 |
| C | 13 | 61 | 6263 | 29.8 | 803 | 807 | 183.1 |
| C | 10 | 22 | 4549 | 20.44 | 803 | 807 | 183.1 |
| D | 2 | 152 | 347759 | 1803.88 | 799 | 774 | 192.4 |
| D | 2 | 14 | 187828 | 972.44 | 799 | 774 | 192.4 |
| D | 2 | 136 | 32835 | 166.68 | 799 | 774 | 192.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
