| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_158T01_9000001064_07715cztM0_level2.evt | modeM0/AS1A02_158T01_9000001064_07715cztM0_level2_quad_clean.evt |
| Size (bytes) | 429,281,280 | 92,059,200 |
| Size | 409.4 MB | 87.8 MB |
| Events in quadrant A | 3,139,106 | 589,318 |
| Events in quadrant B | 3,186,367 | 600,391 |
| Events in quadrant C | 3,110,948 | 591,837 |
| Events in quadrant D | 3,133,451 | 564,138 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13216 | 3 |
| B | 0 | 13312 | 2 |
| C | 0 | 13180 | 2 |
| D | 0 | 13378 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6339 | 75 | 1.183152% |
| B | 6339 | 88 | 1.388232% |
| C | 6339 | 61 | 0.962297% |
| D | 6339 | 75 | 1.183152% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7589 | 6340 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7589 | 6339 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7589 | 6340 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7589 | 6340 | 3 | 3 | 0.04% | 0.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 29057 | 172.8 | 808 | 792 | 163.6 |
| A | 0 | 226 | 7918 | 43.56 | 808 | 792 | 163.6 |
| A | 12 | 194 | 7253 | 39.5 | 808 | 792 | 163.6 |
| B | 4 | 239 | 32974 | 211.88 | 806 | 789 | 151.9 |
| B | 12 | 111 | 14703 | 91.6 | 806 | 789 | 151.9 |
| B | 0 | 214 | 11864 | 72.91 | 806 | 789 | 151.9 |
| C | 1 | 16 | 6011 | 28.23 | 792 | 798 | 184.7 |
| C | 13 | 61 | 5953 | 27.91 | 792 | 798 | 184.7 |
| C | 9 | 68 | 5806 | 27.12 | 792 | 798 | 184.7 |
| D | 2 | 152 | 72029 | 367.28 | 795 | 770 | 194.0 |
| D | 13 | 104 | 30328 | 152.35 | 795 | 770 | 194.0 |
| D | 12 | 0 | 16763 | 82.43 | 795 | 770 | 194.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
