| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_064T01_9000001066_07730cztM0_level2.evt | modeM0/AS1G06_064T01_9000001066_07730cztM0_level2_quad_clean.evt |
| Size (bytes) | 435,421,440 | 95,512,320 |
| Size | 415.3 MB | 91.1 MB |
| Events in quadrant A | 3,133,608 | 618,712 |
| Events in quadrant B | 3,168,836 | 626,948 |
| Events in quadrant C | 3,327,553 | 611,886 |
| Events in quadrant D | 3,118,656 | 585,448 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13384 | 3 |
| B | 0 | 13435 | 2 |
| C | 0 | 13990 | 2 |
| D | 0 | 13490 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6446 | 87 | 1.349674% |
| B | 6446 | 73 | 1.132485% |
| C | 6446 | 71 | 1.101458% |
| D | 6446 | 91 | 1.411728% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7611 | 6447 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7611 | 6447 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7611 | 6447 | 5 | 5 | 0.07% | 0.08% |  |
| D | 7611 | 6447 | 5 | 5 | 0.07% | 0.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 16746 | 97.46 | 807 | 788 | 163.7 |
| A | 0 | 226 | 7637 | 41.83 | 807 | 788 | 163.7 |
| A | 12 | 194 | 7160 | 38.92 | 807 | 788 | 163.7 |
| B | 0 | 214 | 20691 | 130.84 | 804 | 784 | 152.1 |
| B | 12 | 111 | 14375 | 89.33 | 804 | 784 | 152.1 |
| B | 11 | 111 | 11701 | 71.75 | 804 | 784 | 152.1 |
| C | 9 | 68 | 246189 | 1345.13 | 788 | 792 | 182.4 |
| C | 12 | 4 | 7711 | 37.93 | 788 | 792 | 182.4 |
| C | 13 | 61 | 5990 | 28.49 | 788 | 792 | 182.4 |
| D | 2 | 152 | 50613 | 259.08 | 791 | 766 | 192.4 |
| D | 13 | 104 | 21743 | 109.03 | 791 | 766 | 192.4 |
| D | 2 | 16 | 17982 | 89.48 | 791 | 766 | 192.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
