| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_064T01_9000001066_07747cztM0_level2.evt | modeM0/AS1G06_064T01_9000001066_07747cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,957,760 | 85,968,000 |
| Size | 457.7 MB | 82.0 MB |
| Events in quadrant A | 3,553,161 | 527,840 |
| Events in quadrant B | 3,708,849 | 533,417 |
| Events in quadrant C | 3,382,981 | 522,942 |
| Events in quadrant D | 3,385,081 | 501,623 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15634 | 2 |
| B | 0 | 15946 | 1 |
| C | 0 | 15333 | 1 |
| D | 0 | 15446 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7433 | 187 | 2.515808% |
| B | 7433 | 227 | 3.053949% |
| C | 7433 | 123 | 1.654783% |
| D | 7433 | 136 | 1.829678% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7763 | 7433 | 11 | 11 | 0.14% | 0.15% |  |
| B | 7763 | 7433 | 30 | 30 | 0.39% | 0.40% |  |
| C | 7763 | 7433 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7763 | 7433 | 3 | 3 | 0.04% | 0.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 128 | 127885 | 695.54 | 885 | 863 | 182.6 |
| A | 15 | 234 | 13943 | 71.62 | 885 | 863 | 182.6 |
| A | 0 | 226 | 8450 | 41.54 | 885 | 863 | 182.6 |
| B | 4 | 239 | 126021 | 725.72 | 887 | 864 | 172.5 |
| B | 4 | 81 | 74717 | 428.24 | 887 | 864 | 172.5 |
| B | 0 | 214 | 18840 | 104.23 | 887 | 864 | 172.5 |
| C | 13 | 61 | 6823 | 29.42 | 866 | 867 | 202.5 |
| C | 8 | 222 | 3923 | 15.09 | 866 | 867 | 202.5 |
| C | 3 | 202 | 2132 | 6.25 | 866 | 867 | 202.5 |
| D | 2 | 234 | 26905 | 121.46 | 870 | 844 | 214.6 |
| D | 13 | 104 | 21895 | 98.11 | 870 | 844 | 214.6 |
| D | 7 | 55 | 18513 | 82.35 | 870 | 844 | 214.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
