| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_169T01_9000001070_07786cztM0_level2.evt | modeM0/AS1G06_169T01_9000001070_07786cztM0_level2_quad_clean.evt |
| Size (bytes) | 421,456,320 | 75,314,880 |
| Size | 401.9 MB | 71.8 MB |
| Events in quadrant A | 2,929,605 | 467,971 |
| Events in quadrant B | 3,100,661 | 480,034 |
| Events in quadrant C | 2,897,828 | 463,644 |
| Events in quadrant D | 3,414,404 | 436,335 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12661 | 3 |
| B | 0 | 13031 | 2 |
| C | 0 | 12684 | 2 |
| D | 0 | 13898 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6196 | 21 | 0.338928% |
| B | 6196 | 28 | 0.451904% |
| C | 6196 | 12 | 0.193673% |
| D | 6196 | 38 | 0.613299% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7486 | 6197 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7486 | 6197 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7486 | 6196 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7486 | 6197 | 19 | 19 | 0.25% | 0.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7360 | 42.68 | 761 | 744 | 155.0 |
| A | 12 | 194 | 6681 | 38.3 | 761 | 744 | 155.0 |
| A | 13 | 254 | 3177 | 15.7 | 761 | 744 | 155.0 |
| B | 4 | 81 | 36249 | 241.63 | 773 | 757 | 146.9 |
| B | 0 | 219 | 27586 | 182.65 | 773 | 757 | 146.9 |
| B | 12 | 111 | 14698 | 94.91 | 773 | 757 | 146.9 |
| C | 1 | 16 | 8017 | 42.3 | 739 | 743 | 172.0 |
| C | 12 | 4 | 7674 | 40.31 | 739 | 743 | 172.0 |
| C | 13 | 61 | 5751 | 29.12 | 739 | 743 | 172.0 |
| D | 1 | 52 | 482977 | 2700.58 | 729 | 704 | 178.6 |
| D | 13 | 104 | 69687 | 386.28 | 729 | 704 | 178.6 |
| D | 2 | 152 | 49087 | 270.93 | 729 | 704 | 178.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
