| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_032T01_9000001074_07796cztM0_level2.evt | modeM0/AS1G06_032T01_9000001074_07796cztM0_level2_quad_clean.evt |
| Size (bytes) | 777,600,000 | 188,939,520 |
| Size | 741.6 MB | 180.2 MB |
| Events in quadrant A | 5,430,434 | 1,240,197 |
| Events in quadrant B | 5,724,898 | 1,268,357 |
| Events in quadrant C | 5,472,423 | 1,216,889 |
| Events in quadrant D | 6,095,684 | 1,154,674 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24703 | 9 |
| B | 0 | 25223 | 7 |
| C | 0 | 24911 | 9 |
| D | 0 | 27123 | 6 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 250 | 0 |
| B | 0 | 250 | 0 |
| C | 0 | 250 | 0 |
| D | 0 | 250 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12181 | 61 | 0.500780% |
| B | 12181 | 103 | 0.845579% |
| C | 12180 | 30 | 0.246305% |
| D | 12181 | 212 | 1.740415% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 15629 | 12184 | 5 | 5 | 0.03% | 0.04% |  |
| B | 15629 | 12184 | 26 | 26 | 0.17% | 0.21% |  |
| C | 15629 | 12185 | 3 | 3 | 0.02% | 0.02% |  |
| D | 15629 | 12184 | 154 | 154 | 0.99% | 1.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 17141 | 55.23 | 1400 | 1366 | 285.6 |
| A | 15 | 174 | 16618 | 53.4 | 1400 | 1366 | 285.6 |
| A | 0 | 226 | 13078 | 41.01 | 1400 | 1366 | 285.6 |
| B | 4 | 173 | 77102 | 282.96 | 1418 | 1384 | 267.6 |
| B | 4 | 239 | 29253 | 104.15 | 1418 | 1384 | 267.6 |
| B | 0 | 214 | 26929 | 95.46 | 1418 | 1384 | 267.6 |
| C | 9 | 243 | 81952 | 256.1 | 1358 | 1361 | 314.7 |
| C | 12 | 4 | 37133 | 113.67 | 1358 | 1361 | 314.7 |
| C | 1 | 16 | 27542 | 83.2 | 1358 | 1361 | 314.7 |
| D | 2 | 152 | 312836 | 945.83 | 1345 | 1301 | 329.4 |
| D | 1 | 52 | 306189 | 925.65 | 1345 | 1301 | 329.4 |
| D | 13 | 104 | 217717 | 657.04 | 1345 | 1301 | 329.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
