| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_077T02_9000001076_07833cztM0_level2.evt | modeM0/AS1G06_077T02_9000001076_07833cztM0_level2_quad_clean.evt |
| Size (bytes) | 613,972,800 | 114,799,680 |
| Size | 585.5 MB | 109.5 MB |
| Events in quadrant A | 4,052,294 | 719,926 |
| Events in quadrant B | 4,458,665 | 740,284 |
| Events in quadrant C | 4,666,219 | 729,206 |
| Events in quadrant D | 4,839,132 | 695,158 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17670 | 3 |
| B | 0 | 18647 | 2 |
| C | 0 | 19535 | 2 |
| D | 0 | 20212 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 174 | 0 |
| B | 0 | 174 | 0 |
| C | 0 | 174 | 0 |
| D | 0 | 174 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8524 | 152 | 1.783200% |
| B | 8524 | 198 | 2.322853% |
| C | 8524 | 191 | 2.240732% |
| D | 8524 | 220 | 2.580948% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 10209 | 8526 | 0 | 0 | 0.00% | 0.00% |  |
| B | 10209 | 8526 | 36 | 36 | 0.35% | 0.42% |  |
| C | 10209 | 8526 | 8 | 8 | 0.08% | 0.09% |  |
| D | 10209 | 8526 | 71 | 71 | 0.70% | 0.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 14884 | 65.57 | 1045 | 1023 | 211.4 |
| A | 0 | 226 | 9719 | 41.14 | 1045 | 1023 | 211.4 |
| A | 12 | 194 | 9350 | 39.39 | 1045 | 1023 | 211.4 |
| B | 4 | 239 | 169995 | 837.83 | 1052 | 1028 | 201.7 |
| B | 0 | 219 | 70004 | 342.02 | 1052 | 1028 | 201.7 |
| B | 4 | 81 | 36427 | 175.53 | 1052 | 1028 | 201.7 |
| C | 1 | 16 | 626748 | 2635.15 | 1022 | 1028 | 237.5 |
| C | 12 | 4 | 25561 | 103.32 | 1022 | 1028 | 237.5 |
| C | 9 | 54 | 14429 | 56.44 | 1022 | 1028 | 237.5 |
| D | 12 | 33 | 257970 | 1026.7 | 1021 | 988 | 250.3 |
| D | 7 | 71 | 156056 | 619.53 | 1021 | 988 | 250.3 |
| D | 2 | 136 | 121948 | 483.26 | 1021 | 988 | 250.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
