| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_077T02_9000001076_07868cztM0_level2.evt | modeM0/AS1G06_077T02_9000001076_07868cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,371,250,880 | 363,767,040 |
| Size | 2.2 GB | 346.9 MB |
| Events in quadrant A | 18,005,097 | 2,212,946 |
| Events in quadrant B | 16,578,696 | 2,277,152 |
| Events in quadrant C | 18,164,470 | 2,270,276 |
| Events in quadrant D | 16,983,198 | 2,134,631 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 74279 | 5 |
| B | 0 | 69247 | 5 |
| C | 0 | 74731 | 5 |
| D | 0 | 71709 | 5 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 622 | 0 |
| B | 0 | 622 | 0 |
| C | 0 | 622 | 0 |
| D | 0 | 622 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 30882 | 1317 | 4.264620% |
| B | 30882 | 1269 | 4.109190% |
| C | 30882 | 828 | 2.681173% |
| D | 30882 | 1241 | 4.018522% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 32942 | 30887 | 293 | 293 | 0.89% | 0.95% |  |
| B | 32942 | 30887 | 278 | 278 | 0.84% | 0.90% |  |
| C | 32942 | 30887 | 24 | 24 | 0.07% | 0.08% |  |
| D | 32942 | 30887 | 395 | 395 | 1.20% | 1.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 3089260 | 4160.5 | 3692 | 3616 | 741.7 |
| A | 15 | 234 | 489859 | 655.62 | 3692 | 3616 | 741.7 |
| A | 15 | 223 | 93276 | 120.89 | 3692 | 3616 | 741.7 |
| B | 4 | 239 | 1181923 | 1664.54 | 3725 | 3630 | 707.9 |
| B | 4 | 173 | 310953 | 434.15 | 3725 | 3630 | 707.9 |
| B | 0 | 219 | 257598 | 358.77 | 3725 | 3630 | 707.9 |
| C | 1 | 16 | 3726208 | 4441.89 | 3641 | 3666 | 838.1 |
| C | 8 | 229 | 190184 | 222.56 | 3641 | 3666 | 838.1 |
| C | 13 | 61 | 28302 | 29.4 | 3641 | 3666 | 838.1 |
| D | 1 | 52 | 1905812 | 2160.9 | 3623 | 3512 | 880.3 |
| D | 2 | 152 | 525059 | 592.45 | 3623 | 3512 | 880.3 |
| D | 13 | 104 | 229995 | 257.27 | 3623 | 3512 | 880.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
