| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_071T01_9000001078_07887cztM0_level2.evt | modeM0/AS1A02_071T01_9000001078_07887cztM0_level2_quad_clean.evt |
| Size (bytes) | 490,037,760 | 98,648,640 |
| Size | 467.3 MB | 94.1 MB |
| Events in quadrant A | 3,236,802 | 645,666 |
| Events in quadrant B | 3,019,484 | 675,681 |
| Events in quadrant C | 2,953,138 | 659,543 |
| Events in quadrant D | 5,235,837 | 599,058 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13395 | 2 |
| B | 0 | 12688 | 1 |
| C | 0 | 12384 | 1 |
| D | 0 | 19341 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5833 | 149 | 2.554432% |
| B | 5833 | 104 | 1.782959% |
| C | 5833 | 12 | 0.205726% |
| D | 5833 | 406 | 6.960398% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7123 | 5834 | 118 | 118 | 1.66% | 2.02% |  |
| B | 7123 | 5834 | 32 | 32 | 0.45% | 0.55% |  |
| C | 7123 | 5834 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7123 | 5834 | 512 | 512 | 7.19% | 8.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 453998 | 3196.8 | 701 | 685 | 141.8 |
| A | 8 | 15 | 69990 | 488.75 | 701 | 685 | 141.8 |
| A | 15 | 223 | 10935 | 72.28 | 701 | 685 | 141.8 |
| B | 11 | 51 | 120906 | 896.36 | 716 | 701 | 134.1 |
| B | 4 | 239 | 79402 | 586.87 | 716 | 701 | 134.1 |
| B | 0 | 214 | 16350 | 116.69 | 716 | 701 | 134.1 |
| C | 1 | 16 | 215648 | 1328.52 | 701 | 705 | 161.8 |
| C | 13 | 61 | 5295 | 28.37 | 701 | 705 | 161.8 |
| C | 9 | 68 | 3291 | 15.98 | 701 | 705 | 161.8 |
| D | 1 | 52 | 1928378 | 11693.86 | 675 | 656 | 164.8 |
| D | 1 | 20 | 334620 | 2025.88 | 675 | 656 | 164.8 |
| D | 14 | 34 | 222852 | 1347.88 | 675 | 656 | 164.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
