| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_071T01_9000001078_07896cztM0_level2.evt | modeM0/AS1A02_071T01_9000001078_07896cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,120,740,480 | 192,493,440 |
| Size | 1.0 GB | 183.6 MB |
| Events in quadrant A | 7,424,793 | 1,193,119 |
| Events in quadrant B | 7,975,091 | 1,225,578 |
| Events in quadrant C | 9,087,206 | 1,169,379 |
| Events in quadrant D | 8,372,001 | 1,137,984 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 324 | 0 |
| B | 0 | 324 | 0 |
| C | 0 | 324 | 0 |
| D | 0 | 324 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33196 | 4 |
| B | 0 | 34318 | 6 |
| C | 0 | 38404 | 4 |
| D | 0 | 36366 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15978 | 481 | 3.010389% |
| B | 15977 | 509 | 3.185830% |
| C | 15978 | 1191 | 7.453999% |
| D | 15978 | 667 | 4.174490% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 16178 | 15982 | 18 | 18 | 0.11% | 0.11% |  |
| B | 16178 | 15982 | 31 | 31 | 0.19% | 0.19% |  |
| C | 16178 | 15982 | 799 | 799 | 4.94% | 5.00% |  |
| D | 16178 | 15982 | 206 | 206 | 1.27% | 1.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 81221 | 208.16 | 1861 | 1815 | 381.5 |
| A | 13 | 170 | 79195 | 202.85 | 1861 | 1815 | 381.5 |
| A | 8 | 15 | 44603 | 112.17 | 1861 | 1815 | 381.5 |
| B | 4 | 239 | 403009 | 1114.56 | 1876 | 1822 | 360.0 |
| B | 15 | 204 | 80305 | 218.04 | 1876 | 1822 | 360.0 |
| B | 4 | 81 | 49981 | 133.79 | 1876 | 1822 | 360.0 |
| C | 9 | 68 | 2112507 | 5152.02 | 1777 | 1784 | 409.7 |
| C | 8 | 128 | 16819 | 36.7 | 1777 | 1784 | 409.7 |
| C | 13 | 61 | 13829 | 29.4 | 1777 | 1784 | 409.7 |
| D | 1 | 52 | 993383 | 2211.62 | 1824 | 1765 | 448.4 |
| D | 13 | 169 | 123178 | 270.79 | 1824 | 1765 | 448.4 |
| D | 4 | 95 | 104333 | 228.76 | 1824 | 1765 | 448.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
