| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_117T01_9000001086_07937cztM0_level2.evt | modeM0/AS1G06_117T01_9000001086_07937cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,141,440 | 77,587,200 |
| Size | 476.0 MB | 74.0 MB |
| Events in quadrant A | 3,496,581 | 456,435 |
| Events in quadrant B | 3,485,864 | 466,501 |
| Events in quadrant C | 3,301,244 | 465,405 |
| Events in quadrant D | 4,328,249 | 443,982 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15384 | 1 |
| B | 0 | 15414 | 0 |
| C | 0 | 15165 | 0 |
| D | 0 | 18021 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7435 | 156 | 2.098184% |
| B | 7435 | 162 | 2.178884% |
| C | 7435 | 98 | 1.318090% |
| D | 7435 | 200 | 2.689980% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7665 | 7438 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7665 | 7438 | 7 | 7 | 0.09% | 0.09% |  |
| C | 7665 | 7438 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7665 | 7438 | 77 | 77 | 1.00% | 1.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 128 | 97944 | 548.9 | 862 | 840 | 176.9 |
| A | 13 | 14 | 29474 | 161.86 | 862 | 840 | 176.9 |
| A | 15 | 234 | 23947 | 130.62 | 862 | 840 | 176.9 |
| B | 10 | 16 | 53113 | 307.36 | 868 | 846 | 170.1 |
| B | 11 | 51 | 47735 | 275.73 | 868 | 846 | 170.1 |
| B | 12 | 111 | 18842 | 105.83 | 868 | 846 | 170.1 |
| C | 8 | 128 | 11257 | 53.12 | 840 | 841 | 196.1 |
| C | 13 | 61 | 6455 | 28.63 | 840 | 841 | 196.1 |
| C | 8 | 144 | 4595 | 19.14 | 840 | 841 | 196.1 |
| D | 1 | 52 | 913382 | 4425.88 | 834 | 804 | 206.2 |
| D | 14 | 34 | 98692 | 474.74 | 834 | 804 | 206.2 |
| D | 2 | 152 | 47562 | 226.77 | 834 | 804 | 206.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
