| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_117T01_9000001086_07944cztM0_level2.evt | modeM0/AS1G06_117T01_9000001086_07944cztM0_level2_quad_clean.evt |
| Size (bytes) | 451,327,680 | 100,546,560 |
| Size | 430.4 MB | 95.9 MB |
| Events in quadrant A | 3,058,163 | 642,526 |
| Events in quadrant B | 3,296,599 | 663,597 |
| Events in quadrant C | 3,116,217 | 665,026 |
| Events in quadrant D | 3,758,648 | 623,349 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13551 | 3 |
| B | 0 | 14206 | 2 |
| C | 0 | 13738 | 2 |
| D | 0 | 15755 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6456 | 42 | 0.650558% |
| B | 6456 | 80 | 1.239157% |
| C | 6456 | 47 | 0.728005% |
| D | 6456 | 83 | 1.285626% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8871 | 6458 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8871 | 6458 | 13 | 13 | 0.15% | 0.20% |  |
| C | 8871 | 6458 | 1 | 1 | 0.01% | 0.02% |  |
| D | 8871 | 6458 | 32 | 32 | 0.36% | 0.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 234 | 14203 | 84.64 | 786 | 770 | 158.7 |
| A | 13 | 253 | 10678 | 62.43 | 786 | 770 | 158.7 |
| A | 0 | 226 | 7411 | 41.84 | 786 | 770 | 158.7 |
| B | 10 | 245 | 62895 | 414.39 | 797 | 778 | 149.9 |
| B | 11 | 51 | 52587 | 345.62 | 797 | 778 | 149.9 |
| B | 10 | 16 | 31793 | 206.9 | 797 | 778 | 149.9 |
| C | 1 | 16 | 48519 | 262.93 | 785 | 789 | 181.5 |
| C | 13 | 61 | 5941 | 28.38 | 785 | 789 | 181.5 |
| C | 9 | 54 | 3316 | 13.92 | 785 | 789 | 181.5 |
| D | 1 | 52 | 693332 | 3704.12 | 775 | 753 | 187.0 |
| D | 5 | 233 | 62583 | 330.69 | 775 | 753 | 187.0 |
| D | 2 | 234 | 21246 | 109.6 | 775 | 753 | 187.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
