| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_077T01_9000001090_07975cztM0_level2.evt | modeM0/AS1G06_077T01_9000001090_07975cztM0_level2_quad_clean.evt |
| Size (bytes) | 460,088,640 | 94,034,880 |
| Size | 438.8 MB | 89.7 MB |
| Events in quadrant A | 2,996,756 | 605,730 |
| Events in quadrant B | 3,105,494 | 634,945 |
| Events in quadrant C | 3,058,682 | 630,101 |
| Events in quadrant D | 4,353,175 | 545,716 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12916 | 3 |
| B | 0 | 13081 | 2 |
| C | 0 | 13154 | 2 |
| D | 0 | 17235 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6174 | 34 | 0.550696% |
| B | 6174 | 47 | 0.761257% |
| C | 6174 | 38 | 0.615484% |
| D | 6174 | 527 | 8.535795% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7514 | 6175 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7514 | 6175 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7514 | 6175 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7514 | 6175 | 400 | 400 | 5.32% | 6.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 128 | 26850 | 168.51 | 764 | 749 | 154.9 |
| A | 13 | 251 | 12090 | 73.22 | 764 | 749 | 154.9 |
| A | 0 | 254 | 10250 | 61.34 | 764 | 749 | 154.9 |
| B | 4 | 97 | 66044 | 445.77 | 779 | 763 | 146.4 |
| B | 12 | 111 | 15822 | 102.83 | 779 | 763 | 146.4 |
| B | 4 | 239 | 14120 | 91.21 | 779 | 763 | 146.4 |
| C | 1 | 16 | 69841 | 392.0 | 763 | 768 | 176.2 |
| C | 13 | 61 | 5802 | 28.57 | 763 | 768 | 176.2 |
| C | 8 | 143 | 5253 | 25.45 | 763 | 768 | 176.2 |
| D | 1 | 52 | 972147 | 5603.01 | 716 | 696 | 173.4 |
| D | 1 | 20 | 302623 | 1741.41 | 716 | 696 | 173.4 |
| D | 2 | 14 | 208392 | 1197.92 | 716 | 696 | 173.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
