| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_028T01_9000001094_07988cztM0_level2.evt | modeM0/AS1G06_028T01_9000001094_07988cztM0_level2_quad_clean.evt |
| Size (bytes) | 389,088,000 | 70,580,160 |
| Size | 371.1 MB | 67.3 MB |
| Events in quadrant A | 3,073,119 | 440,431 |
| Events in quadrant B | 2,634,512 | 455,178 |
| Events in quadrant C | 3,244,324 | 461,928 |
| Events in quadrant D | 2,504,870 | 442,351 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12328 | 2 |
| B | 0 | 10996 | 1 |
| C | 0 | 12810 | 1 |
| D | 0 | 10671 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 98 | 0 |
| B | 0 | 98 | 0 |
| C | 0 | 98 | 0 |
| D | 0 | 98 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4806 | 83 | 1.727008% |
| B | 4806 | 110 | 2.288806% |
| C | 4806 | 229 | 4.764877% |
| D | 4806 | 96 | 1.997503% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6076 | 4807 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6076 | 4807 | 29 | 29 | 0.48% | 0.60% |  |
| C | 6076 | 4807 | 76 | 76 | 1.25% | 1.58% |  |
| D | 6076 | 4807 | 12 | 12 | 0.20% | 0.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 128 | 684079 | 5436.15 | 616 | 603 | 125.7 |
| A | 13 | 251 | 7400 | 54.06 | 616 | 603 | 125.7 |
| A | 0 | 226 | 5831 | 41.58 | 616 | 603 | 125.7 |
| B | 5 | 250 | 113301 | 959.3 | 621 | 607 | 117.5 |
| B | 4 | 239 | 45651 | 383.43 | 621 | 607 | 117.5 |
| B | 11 | 51 | 42956 | 360.49 | 621 | 607 | 117.5 |
| C | 1 | 16 | 840642 | 5890.58 | 614 | 620 | 142.6 |
| C | 8 | 143 | 8606 | 56.0 | 614 | 620 | 142.6 |
| C | 13 | 61 | 4621 | 28.06 | 614 | 620 | 142.6 |
| D | 1 | 52 | 139447 | 858.43 | 608 | 593 | 161.8 |
| D | 12 | 233 | 17359 | 103.65 | 608 | 593 | 161.8 |
| D | 2 | 136 | 15131 | 89.88 | 608 | 593 | 161.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
