| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_138T03_9000001096_08001cztM0_level2.evt | modeM0/AS1G06_138T03_9000001096_08001cztM0_level2_quad_clean.evt |
| Size (bytes) | 468,849,600 | 90,002,880 |
| Size | 447.1 MB | 85.8 MB |
| Events in quadrant A | 3,286,661 | 560,790 |
| Events in quadrant B | 3,401,568 | 572,798 |
| Events in quadrant C | 3,531,168 | 567,494 |
| Events in quadrant D | 3,516,166 | 548,978 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14370 | 3 |
| B | 0 | 14686 | 2 |
| C | 0 | 14893 | 2 |
| D | 0 | 15088 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6825 | 81 | 1.186813% |
| B | 6825 | 104 | 1.523810% |
| C | 6825 | 86 | 1.260073% |
| D | 6825 | 105 | 1.538462% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8990 | 6827 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8990 | 6827 | 3 | 3 | 0.03% | 0.04% |  |
| C | 8990 | 6827 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8990 | 6827 | 27 | 27 | 0.30% | 0.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7853 | 40.73 | 850 | 832 | 172.4 |
| A | 12 | 194 | 7415 | 38.19 | 850 | 832 | 172.4 |
| A | 13 | 251 | 7039 | 36.01 | 850 | 832 | 172.4 |
| B | 11 | 51 | 48188 | 290.83 | 853 | 832 | 162.8 |
| B | 5 | 255 | 34708 | 208.05 | 853 | 832 | 162.8 |
| B | 12 | 111 | 18255 | 107.0 | 853 | 832 | 162.8 |
| C | 8 | 208 | 239024 | 1228.29 | 839 | 842 | 193.9 |
| C | 1 | 16 | 9635 | 45.35 | 839 | 842 | 193.9 |
| C | 12 | 4 | 7602 | 34.86 | 839 | 842 | 193.9 |
| D | 1 | 52 | 186829 | 933.57 | 832 | 812 | 199.3 |
| D | 4 | 95 | 88190 | 438.53 | 832 | 812 | 199.3 |
| D | 2 | 136 | 41627 | 204.84 | 832 | 812 | 199.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
