| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_154T02_9000001102_08024cztM0_level2.evt | modeM0/AS1G06_154T02_9000001102_08024cztM0_level2_quad_clean.evt |
| Size (bytes) | 502,450,560 | 96,327,360 |
| Size | 479.2 MB | 91.9 MB |
| Events in quadrant A | 3,597,936 | 586,345 |
| Events in quadrant B | 3,677,046 | 603,592 |
| Events in quadrant C | 3,578,595 | 606,083 |
| Events in quadrant D | 3,833,005 | 578,447 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16187 | 10 |
| B | 0 | 16209 | 3 |
| C | 0 | 16174 | 5 |
| D | 0 | 17166 | 5 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7796 | 229 | 2.937404% |
| B | 7799 | 277 | 3.551737% |
| C | 7798 | 133 | 1.705566% |
| D | 7798 | 204 | 2.616055% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8005 | 7802 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8005 | 7802 | 0 | 0 | 0.00% | 0.00% |  |
| C | 8005 | 7802 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8005 | 7802 | 63 | 63 | 0.79% | 0.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 8745 | 40.32 | 933 | 910 | 194.3 |
| A | 12 | 194 | 8483 | 38.98 | 933 | 910 | 194.3 |
| A | 13 | 254 | 4377 | 17.84 | 933 | 910 | 194.3 |
| B | 5 | 255 | 24595 | 128.16 | 937 | 912 | 184.8 |
| B | 12 | 111 | 21179 | 109.67 | 937 | 912 | 184.8 |
| B | 11 | 111 | 17272 | 88.53 | 937 | 912 | 184.8 |
| C | 13 | 61 | 6948 | 28.1 | 913 | 913 | 214.7 |
| C | 8 | 128 | 5510 | 21.41 | 913 | 913 | 214.7 |
| C | 8 | 222 | 5193 | 19.93 | 913 | 913 | 214.7 |
| D | 1 | 52 | 186879 | 849.97 | 905 | 881 | 218.8 |
| D | 2 | 14 | 143250 | 650.59 | 905 | 881 | 218.8 |
| D | 13 | 169 | 70561 | 318.42 | 905 | 881 | 218.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
