| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_033T01_9000001116_08107cztM0_level2.evt | modeM0/AS1G06_033T01_9000001116_08107cztM0_level2_quad_clean.evt |
| Size (bytes) | 469,946,880 | 84,723,840 |
| Size | 448.2 MB | 80.8 MB |
| Events in quadrant A | 3,796,326 | 526,658 |
| Events in quadrant B | 3,304,163 | 535,665 |
| Events in quadrant C | 3,151,014 | 540,849 |
| Events in quadrant D | 3,544,413 | 514,150 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15643 | 3 |
| B | 0 | 13866 | 2 |
| C | 0 | 13401 | 2 |
| D | 0 | 14798 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6427 | 42 | 0.653493% |
| B | 6427 | 55 | 0.855765% |
| C | 6427 | 16 | 0.248950% |
| D | 6427 | 195 | 3.034075% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7582 | 6428 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7582 | 6428 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7582 | 6428 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7582 | 6428 | 147 | 147 | 1.94% | 2.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 675507 | 4089.02 | 810 | 794 | 165.0 |
| A | 0 | 226 | 7542 | 40.9 | 810 | 794 | 165.0 |
| A | 12 | 194 | 7180 | 38.7 | 810 | 794 | 165.0 |
| B | 11 | 51 | 58119 | 367.42 | 820 | 802 | 156.0 |
| B | 10 | 16 | 26109 | 162.23 | 820 | 802 | 156.0 |
| B | 0 | 214 | 23117 | 143.05 | 820 | 802 | 156.0 |
| C | 1 | 16 | 19747 | 102.05 | 802 | 809 | 185.6 |
| C | 13 | 61 | 6132 | 28.68 | 802 | 809 | 185.6 |
| C | 14 | 67 | 3151 | 12.62 | 802 | 809 | 185.6 |
| D | 1 | 52 | 496506 | 2420.47 | 781 | 764 | 204.8 |
| D | 12 | 233 | 52710 | 253.63 | 781 | 764 | 204.8 |
| D | 5 | 233 | 26999 | 128.09 | 781 | 764 | 204.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
