| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_033T01_9000001116_08110cztM0_level2.evt | modeM0/AS1G06_033T01_9000001116_08110cztM0_level2_quad_clean.evt |
| Size (bytes) | 586,843,200 | 105,834,240 |
| Size | 559.7 MB | 100.9 MB |
| Events in quadrant A | 4,387,440 | 654,001 |
| Events in quadrant B | 4,240,565 | 665,337 |
| Events in quadrant C | 4,009,914 | 672,944 |
| Events in quadrant D | 4,569,728 | 634,258 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 168 | 0 |
| B | 0 | 168 | 0 |
| C | 0 | 168 | 0 |
| D | 0 | 168 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18675 | 3 |
| B | 0 | 18139 | 2 |
| C | 0 | 17521 | 2 |
| D | 0 | 19427 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8330 | 167 | 2.004802% |
| B | 8330 | 230 | 2.761104% |
| C | 8330 | 62 | 0.744298% |
| D | 8330 | 142 | 1.704682% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8710 | 8332 | 4 | 4 | 0.05% | 0.05% |  |
| B | 8710 | 8332 | 3 | 3 | 0.03% | 0.04% |  |
| C | 8710 | 8332 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8710 | 8332 | 30 | 30 | 0.34% | 0.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 322917 | 1481.29 | 1045 | 1023 | 217.3 |
| A | 0 | 128 | 38882 | 174.22 | 1045 | 1023 | 217.3 |
| A | 0 | 226 | 9818 | 40.47 | 1045 | 1023 | 217.3 |
| B | 11 | 51 | 51598 | 244.89 | 1057 | 1031 | 206.5 |
| B | 0 | 214 | 42137 | 199.07 | 1057 | 1031 | 206.5 |
| B | 10 | 16 | 22148 | 102.27 | 1057 | 1031 | 206.5 |
| C | 1 | 16 | 13025 | 49.89 | 1023 | 1030 | 240.4 |
| C | 13 | 61 | 7828 | 28.28 | 1023 | 1030 | 240.4 |
| C | 8 | 128 | 5109 | 16.97 | 1023 | 1030 | 240.4 |
| D | 5 | 233 | 364875 | 1456.34 | 1013 | 985 | 249.9 |
| D | 1 | 52 | 254926 | 1016.31 | 1013 | 985 | 249.9 |
| D | 13 | 238 | 57640 | 226.74 | 1013 | 985 | 249.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
