| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_178T01_9000001118_08123cztM0_level2.evt | modeM0/AS1A02_178T01_9000001118_08123cztM0_level2_quad_clean.evt |
| Size (bytes) | 485,904,960 | 100,126,080 |
| Size | 463.4 MB | 95.5 MB |
| Events in quadrant A | 3,363,478 | 631,024 |
| Events in quadrant B | 3,658,470 | 646,630 |
| Events in quadrant C | 3,364,687 | 636,237 |
| Events in quadrant D | 3,827,103 | 604,183 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15198 | 3 |
| B | 0 | 15917 | 2 |
| C | 0 | 15165 | 2 |
| D | 0 | 16704 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7387 | 37 | 0.500880% |
| B | 7387 | 101 | 1.367267% |
| C | 7387 | 22 | 0.297820% |
| D | 7387 | 95 | 1.286043% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7897 | 7388 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7897 | 7388 | 40 | 40 | 0.51% | 0.54% |  |
| C | 7897 | 7388 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7897 | 7388 | 36 | 36 | 0.46% | 0.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 23997 | 129.8 | 866 | 845 | 178.4 |
| A | 0 | 226 | 8077 | 40.55 | 866 | 845 | 178.4 |
| A | 12 | 194 | 7797 | 38.98 | 866 | 845 | 178.4 |
| B | 10 | 16 | 224290 | 1326.09 | 879 | 857 | 168.5 |
| B | 12 | 111 | 18563 | 105.09 | 879 | 857 | 168.5 |
| B | 11 | 111 | 14605 | 81.6 | 879 | 857 | 168.5 |
| C | 1 | 16 | 33797 | 164.05 | 854 | 857 | 200.8 |
| C | 13 | 61 | 6637 | 28.79 | 854 | 857 | 200.8 |
| C | 3 | 202 | 2023 | 5.81 | 854 | 857 | 200.8 |
| D | 1 | 52 | 338650 | 1647.38 | 842 | 818 | 205.1 |
| D | 2 | 152 | 103435 | 500.39 | 842 | 818 | 205.1 |
| D | 12 | 221 | 54813 | 263.3 | 842 | 818 | 205.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
