| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_178T01_9000001118_08125cztM0_level2.evt | modeM0/AS1A02_178T01_9000001118_08125cztM0_level2_quad_clean.evt |
| Size (bytes) | 531,774,720 | 111,035,520 |
| Size | 507.1 MB | 105.9 MB |
| Events in quadrant A | 3,692,350 | 705,776 |
| Events in quadrant B | 3,840,043 | 725,426 |
| Events in quadrant C | 3,700,389 | 708,554 |
| Events in quadrant D | 4,328,825 | 667,061 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16641 | 9 |
| B | 0 | 16924 | 4 |
| C | 0 | 16620 | 14 |
| D | 0 | 18331 | 17 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7992 | 139 | 1.739239% |
| B | 7994 | 212 | 2.651989% |
| C | 7989 | 165 | 2.065340% |
| D | 7990 | 310 | 3.879850% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8225 | 7999 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8225 | 7999 | 14 | 14 | 0.17% | 0.18% |  |
| C | 8225 | 7997 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8225 | 7998 | 90 | 90 | 1.09% | 1.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 79 | 13549 | 64.87 | 951 | 929 | 194.5 |
| A | 8 | 15 | 12428 | 59.11 | 951 | 929 | 194.5 |
| A | 0 | 226 | 8974 | 41.35 | 951 | 929 | 194.5 |
| B | 10 | 16 | 69153 | 369.96 | 959 | 934 | 184.4 |
| B | 0 | 214 | 29804 | 156.56 | 959 | 934 | 184.4 |
| B | 12 | 111 | 20838 | 107.94 | 959 | 934 | 184.4 |
| C | 1 | 16 | 29589 | 130.78 | 940 | 943 | 219.0 |
| C | 13 | 61 | 7013 | 27.71 | 940 | 943 | 219.0 |
| C | 8 | 222 | 2918 | 9.02 | 940 | 943 | 219.0 |
| D | 12 | 221 | 479539 | 2049.46 | 912 | 888 | 233.6 |
| D | 1 | 52 | 222259 | 947.85 | 912 | 888 | 233.6 |
| D | 12 | 233 | 108608 | 461.23 | 912 | 888 | 233.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
