| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_043T01_9000001126_08178cztM0_level2.evt | modeM0/AS1G07_043T01_9000001126_08178cztM0_level2_quad_clean.evt |
| Size (bytes) | 462,565,440 | 70,986,240 |
| Size | 441.1 MB | 67.7 MB |
| Events in quadrant A | 3,201,921 | 428,920 |
| Events in quadrant B | 3,424,255 | 431,771 |
| Events in quadrant C | 3,055,833 | 437,575 |
| Events in quadrant D | 3,898,070 | 410,535 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13267 | 2 |
| B | 0 | 14070 | 1 |
| C | 0 | 12962 | 1 |
| D | 0 | 15579 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6320 | 109 | 1.724684% |
| B | 6320 | 149 | 2.357595% |
| C | 6320 | 82 | 1.297468% |
| D | 6320 | 175 | 2.768987% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7560 | 6320 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7560 | 6320 | 31 | 31 | 0.41% | 0.49% |  |
| C | 7560 | 6320 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7560 | 6320 | 76 | 76 | 1.01% | 1.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 89673 | 541.08 | 806 | 788 | 164.3 |
| A | 0 | 226 | 7724 | 42.22 | 806 | 788 | 164.3 |
| A | 12 | 194 | 7460 | 40.61 | 806 | 788 | 164.3 |
| B | 0 | 213 | 186132 | 1236.68 | 800 | 782 | 149.9 |
| B | 0 | 214 | 58515 | 385.2 | 800 | 782 | 149.9 |
| B | 4 | 173 | 21027 | 135.08 | 800 | 782 | 149.9 |
| C | 13 | 61 | 6090 | 29.53 | 783 | 786 | 179.6 |
| C | 3 | 202 | 2063 | 7.11 | 783 | 786 | 179.6 |
| C | -1 | -1 | -1 | -1.0 | 783 | 786 | 179.6 |
| D | 13 | 122 | 399423 | 2103.2 | 783 | 760 | 189.6 |
| D | 1 | 52 | 267078 | 1405.0 | 783 | 760 | 189.6 |
| D | 2 | 136 | 55939 | 291.1 | 783 | 760 | 189.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
