| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_036T01_9000001128_08179cztM0_level2.evt | modeM0/AS1A03_036T01_9000001128_08179cztM0_level2_quad_clean.evt |
| Size (bytes) | 168,157,440 | 28,975,680 |
| Size | 160.4 MB | 27.6 MB |
| Events in quadrant A | 1,169,519 | 180,757 |
| Events in quadrant B | 1,199,143 | 183,749 |
| Events in quadrant C | 1,138,237 | 179,577 |
| Events in quadrant D | 1,430,544 | 170,382 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 48 | 0 |
| B | 0 | 48 | 0 |
| C | 0 | 48 | 0 |
| D | 0 | 48 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4848 | 2 |
| B | 0 | 4925 | 1 |
| C | 0 | 4765 | 1 |
| D | 0 | 5702 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2245 | 71 | 3.162584% |
| B | 2245 | 63 | 2.806236% |
| C | 2245 | 70 | 3.118040% |
| D | 2245 | 109 | 4.855234% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3375 | 2246 | 1 | 1 | 0.03% | 0.04% |  |
| B | 3375 | 2246 | 3 | 3 | 0.09% | 0.13% |  |
| C | 3375 | 2246 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3375 | 2246 | 25 | 25 | 0.74% | 1.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 16305 | 257.28 | 297 | 289 | 62.3 |
| A | 5 | 16 | 5106 | 77.38 | 297 | 289 | 62.3 |
| A | 3 | 1 | 3034 | 44.09 | 297 | 289 | 62.3 |
| B | 0 | 213 | 30721 | 527.82 | 295 | 287 | 57.7 |
| B | 0 | 219 | 9014 | 151.35 | 295 | 287 | 57.7 |
| B | 12 | 111 | 5774 | 95.16 | 295 | 287 | 57.7 |
| C | 13 | 61 | 2186 | 27.52 | 291 | 291 | 68.9 |
| C | 6 | 15 | 894 | 8.76 | 291 | 291 | 68.9 |
| C | 7 | 159 | 811 | 7.55 | 291 | 291 | 68.9 |
| D | 12 | 227 | 84092 | 1158.0 | 289 | 279 | 72.4 |
| D | 13 | 105 | 64638 | 889.22 | 289 | 279 | 72.4 |
| D | 12 | 233 | 46396 | 637.18 | 289 | 279 | 72.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
