| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_036T01_9000001128_08189cztM0_level2.evt | modeM0/AS1A03_036T01_9000001128_08189cztM0_level2_quad_clean.evt |
| Size (bytes) | 533,862,720 | 92,180,160 |
| Size | 509.1 MB | 87.9 MB |
| Events in quadrant A | 3,481,135 | 581,584 |
| Events in quadrant B | 3,693,055 | 587,413 |
| Events in quadrant C | 3,375,728 | 576,837 |
| Events in quadrant D | 5,119,524 | 534,616 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15142 | 3 |
| B | 0 | 15648 | 2 |
| C | 0 | 15037 | 2 |
| D | 0 | 20152 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7343 | 126 | 1.715920% |
| B | 7343 | 143 | 1.947433% |
| C | 7343 | 89 | 1.212039% |
| D | 7343 | 556 | 7.571837% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9343 | 7343 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9343 | 7343 | 5 | 5 | 0.05% | 0.07% |  |
| C | 9343 | 7344 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9343 | 7343 | 446 | 446 | 4.77% | 6.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 14 | 23188 | 122.23 | 895 | 876 | 182.5 |
| A | 8 | 15 | 13499 | 69.15 | 895 | 876 | 182.5 |
| A | 0 | 226 | 8537 | 41.97 | 895 | 876 | 182.5 |
| B | 4 | 81 | 68811 | 399.03 | 895 | 873 | 170.3 |
| B | 10 | 16 | 59928 | 346.85 | 895 | 873 | 170.3 |
| B | 0 | 214 | 56929 | 329.24 | 895 | 873 | 170.3 |
| C | 13 | 61 | 6547 | 28.19 | 865 | 869 | 201.4 |
| C | 3 | 202 | 2125 | 6.24 | 865 | 869 | 201.4 |
| C | -1 | -1 | -1 | -1.0 | 865 | 869 | 201.4 |
| D | 12 | 233 | 1209700 | 5579.53 | 841 | 820 | 216.7 |
| D | 1 | 52 | 317721 | 1462.64 | 841 | 820 | 216.7 |
| D | 13 | 105 | 137442 | 630.57 | 841 | 820 | 216.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
