| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_070T01_9000001138_08233cztM0_level2.evt | modeM0/AS1G07_070T01_9000001138_08233cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,563,520 | 67,337,280 |
| Size | 461.2 MB | 64.2 MB |
| Events in quadrant A | 3,286,128 | 403,098 |
| Events in quadrant B | 3,359,704 | 406,572 |
| Events in quadrant C | 3,379,815 | 401,553 |
| Events in quadrant D | 4,186,156 | 382,613 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13830 | 3 |
| B | 0 | 13876 | 2 |
| C | 0 | 14411 | 2 |
| D | 0 | 16914 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6380 | 121 | 1.896552% |
| B | 6380 | 96 | 1.504702% |
| C | 6380 | 65 | 1.018809% |
| D | 6380 | 309 | 4.843260% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7530 | 6380 | 39 | 39 | 0.52% | 0.61% |  |
| B | 7530 | 6380 | 12 | 12 | 0.16% | 0.19% |  |
| C | 7530 | 6380 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7530 | 6380 | 214 | 214 | 2.84% | 3.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 182141 | 1133.61 | 793 | 778 | 160.0 |
| A | 8 | 15 | 31316 | 190.88 | 793 | 778 | 160.0 |
| A | 15 | 234 | 18937 | 113.5 | 793 | 778 | 160.0 |
| B | 0 | 214 | 71388 | 461.51 | 801 | 781 | 153.0 |
| B | 11 | 51 | 68002 | 439.38 | 801 | 781 | 153.0 |
| B | 10 | 16 | 58758 | 378.95 | 801 | 781 | 153.0 |
| C | 9 | 68 | 298710 | 1659.16 | 774 | 776 | 179.6 |
| C | 1 | 16 | 41030 | 224.17 | 774 | 776 | 179.6 |
| C | 8 | 128 | 12519 | 65.4 | 774 | 776 | 179.6 |
| D | 1 | 52 | 1076728 | 5806.19 | 762 | 739 | 185.3 |
| D | 13 | 105 | 182963 | 983.31 | 762 | 739 | 185.3 |
| D | 12 | 233 | 25281 | 132.43 | 762 | 739 | 185.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
