| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_070T01_9000001138_08234cztM0_level2.evt | modeM0/AS1G07_070T01_9000001138_08234cztM0_level2_quad_clean.evt |
| Size (bytes) | 520,686,720 | 82,186,560 |
| Size | 496.6 MB | 78.4 MB |
| Events in quadrant A | 3,527,654 | 515,472 |
| Events in quadrant B | 3,520,466 | 525,130 |
| Events in quadrant C | 3,151,942 | 517,603 |
| Events in quadrant D | 5,133,484 | 482,611 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14399 | 3 |
| B | 0 | 14348 | 2 |
| C | 0 | 13535 | 2 |
| D | 0 | 19699 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6419 | 119 | 1.853871% |
| B | 6419 | 138 | 2.149868% |
| C | 6419 | 85 | 1.324194% |
| D | 6419 | 464 | 7.228540% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8814 | 6419 | 21 | 21 | 0.24% | 0.33% |  |
| B | 8814 | 6420 | 24 | 24 | 0.27% | 0.37% |  |
| C | 8814 | 6420 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8814 | 6419 | 354 | 354 | 4.02% | 5.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 79 | 206122 | 1211.39 | 833 | 815 | 169.5 |
| A | 5 | 16 | 99376 | 581.55 | 833 | 815 | 169.5 |
| A | 15 | 234 | 13992 | 77.75 | 833 | 815 | 169.5 |
| B | 10 | 16 | 154247 | 968.29 | 834 | 815 | 158.5 |
| B | 11 | 51 | 71232 | 444.39 | 834 | 815 | 158.5 |
| B | 0 | 214 | 32910 | 202.55 | 834 | 815 | 158.5 |
| C | 13 | 61 | 6179 | 28.97 | 807 | 812 | 185.3 |
| C | 1 | 16 | 3018 | 11.91 | 807 | 812 | 185.3 |
| C | 12 | 4 | 2325 | 8.17 | 807 | 812 | 185.3 |
| D | 1 | 52 | 2028493 | 10455.86 | 794 | 769 | 193.9 |
| D | 13 | 105 | 63424 | 323.08 | 794 | 769 | 193.9 |
| D | 2 | 234 | 22913 | 114.18 | 794 | 769 | 193.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
