| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_136T01_9000001148_08263cztM0_level2.evt | modeM0/AS1G06_136T01_9000001148_08263cztM0_level2_quad_clean.evt |
| Size (bytes) | 496,319,040 | 68,794,560 |
| Size | 473.3 MB | 65.6 MB |
| Events in quadrant A | 4,273,710 | 392,614 |
| Events in quadrant B | 3,415,615 | 417,118 |
| Events in quadrant C | 3,228,662 | 415,047 |
| Events in quadrant D | 3,667,848 | 400,778 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16746 | 3 |
| B | 0 | 14004 | 2 |
| C | 0 | 13608 | 2 |
| D | 0 | 15112 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6554 | 316 | 4.821483% |
| B | 6554 | 81 | 1.235886% |
| C | 6554 | 31 | 0.472994% |
| D | 6554 | 125 | 1.907232% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7794 | 6555 | 221 | 221 | 2.84% | 3.37% |  |
| B | 7794 | 6554 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7794 | 6555 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7794 | 6555 | 24 | 24 | 0.31% | 0.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 128 | 995958 | 5798.4 | 848 | 831 | 171.6 |
| A | 13 | 248 | 12489 | 67.93 | 848 | 831 | 171.6 |
| A | 0 | 226 | 8061 | 42.13 | 848 | 831 | 171.6 |
| B | 10 | 16 | 31302 | 186.93 | 855 | 836 | 163.0 |
| B | 0 | 214 | 30821 | 183.98 | 855 | 836 | 163.0 |
| B | 11 | 51 | 24756 | 146.77 | 855 | 836 | 163.0 |
| C | 13 | 61 | 6277 | 28.5 | 827 | 834 | 191.0 |
| C | 12 | 4 | 3026 | 11.48 | 827 | 834 | 191.0 |
| C | 3 | 202 | 2000 | 6.11 | 827 | 834 | 191.0 |
| D | 2 | 136 | 172400 | 864.87 | 831 | 812 | 198.4 |
| D | 1 | 52 | 164016 | 822.61 | 831 | 812 | 198.4 |
| D | 2 | 152 | 86200 | 430.39 | 831 | 812 | 198.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
