| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_163T01_9000001152_08301cztM0_level2.evt | modeM0/AS1T01_163T01_9000001152_08301cztM0_level2_quad_clean.evt |
| Size (bytes) | 627,966,720 | 112,893,120 |
| Size | 598.9 MB | 107.7 MB |
| Events in quadrant A | 4,520,288 | 684,357 |
| Events in quadrant B | 4,836,747 | 689,841 |
| Events in quadrant C | 4,476,580 | 679,718 |
| Events in quadrant D | 4,492,817 | 659,021 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20756 | 6 |
| B | 0 | 21462 | 2 |
| C | 0 | 20738 | 4 |
| D | 0 | 21090 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 210 | 0 |
| B | 0 | 210 | 0 |
| C | 0 | 210 | 0 |
| D | 0 | 210 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10180 | 51 | 0.500982% |
| B | 10181 | 83 | 0.815244% |
| C | 10180 | 24 | 0.235756% |
| D | 10181 | 38 | 0.373244% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11041 | 10183 | 2 | 2 | 0.02% | 0.02% |  |
| B | 11041 | 10183 | 12 | 12 | 0.11% | 0.12% |  |
| C | 11041 | 10183 | 2 | 2 | 0.02% | 0.02% |  |
| D | 11041 | 10183 | 24 | 24 | 0.22% | 0.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 11318 | 42.44 | 1163 | 1135 | 239.9 |
| A | 0 | 226 | 11312 | 42.41 | 1163 | 1135 | 239.9 |
| A | 13 | 14 | 10886 | 40.64 | 1163 | 1135 | 239.9 |
| B | 0 | 214 | 150729 | 666.58 | 1169 | 1137 | 224.4 |
| B | 4 | 80 | 64687 | 283.18 | 1169 | 1137 | 224.4 |
| B | 4 | 81 | 33764 | 145.39 | 1169 | 1137 | 224.4 |
| C | 10 | 9 | 65226 | 243.57 | 1130 | 1137 | 263.1 |
| C | 13 | 61 | 8744 | 28.91 | 1130 | 1137 | 263.1 |
| C | 9 | 54 | 5648 | 17.14 | 1130 | 1137 | 263.1 |
| D | 2 | 14 | 111070 | 367.4 | 1121 | 1093 | 299.3 |
| D | 2 | 234 | 37631 | 122.06 | 1121 | 1093 | 299.3 |
| D | 8 | 230 | 30457 | 98.1 | 1121 | 1093 | 299.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
