| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_028T01_9000001166_08375cztM0_level2.evt | modeM0/AS1G07_028T01_9000001166_08375cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,593,920 | 94,907,520 |
| Size | 437.3 MB | 90.5 MB |
| Events in quadrant A | 2,951,980 | 615,870 |
| Events in quadrant B | 3,823,128 | 605,213 |
| Events in quadrant C | 2,966,655 | 620,188 |
| Events in quadrant D | 3,708,870 | 583,258 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13132 | 2 |
| B | 0 | 15661 | 3 |
| C | 0 | 13201 | 1 |
| D | 0 | 15506 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6447 | 21 | 0.325733% |
| B | 6446 | 233 | 3.614645% |
| C | 6447 | 20 | 0.310222% |
| D | 6447 | 184 | 2.854041% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7397 | 6448 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7397 | 6448 | 149 | 149 | 2.01% | 2.31% |  |
| C | 7397 | 6448 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7397 | 6448 | 134 | 134 | 1.81% | 2.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7186 | 40.71 | 767 | 752 | 158.1 |
| A | 12 | 194 | 6822 | 38.41 | 767 | 752 | 158.1 |
| A | 3 | 137 | 2994 | 14.19 | 767 | 752 | 158.1 |
| B | 10 | 16 | 580663 | 3931.82 | 763 | 744 | 147.5 |
| B | 4 | 81 | 108449 | 730.23 | 763 | 744 | 147.5 |
| B | 0 | 214 | 98221 | 660.89 | 763 | 744 | 147.5 |
| C | 1 | 16 | 36752 | 205.43 | 751 | 755 | 175.2 |
| C | 13 | 61 | 5770 | 28.62 | 751 | 755 | 175.2 |
| C | 8 | 208 | 3335 | 14.72 | 751 | 755 | 175.2 |
| D | 11 | 144 | 409254 | 2266.94 | 739 | 719 | 180.2 |
| D | 13 | 169 | 117986 | 650.71 | 739 | 719 | 180.2 |
| D | 8 | 195 | 100923 | 556.03 | 739 | 719 | 180.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
