| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_053T01_9000001186_08421cztM0_level2.evt | modeM0/AS1G07_053T01_9000001186_08421cztM0_level2_quad_clean.evt |
| Size (bytes) | 444,240,000 | 98,723,520 |
| Size | 423.7 MB | 94.2 MB |
| Events in quadrant A | 3,166,093 | 633,019 |
| Events in quadrant B | 3,471,726 | 647,490 |
| Events in quadrant C | 3,161,448 | 640,808 |
| Events in quadrant D | 3,200,691 | 603,093 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13704 | 3 |
| B | 0 | 14612 | 2 |
| C | 0 | 13696 | 2 |
| D | 0 | 14084 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6674 | 25 | 0.374588% |
| B | 6674 | 97 | 1.453401% |
| C | 6674 | 23 | 0.344621% |
| D | 6674 | 34 | 0.509440% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7824 | 6675 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7824 | 6675 | 31 | 31 | 0.40% | 0.46% |  |
| C | 7824 | 6675 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7824 | 6675 | 12 | 12 | 0.15% | 0.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 12618 | 70.92 | 816 | 801 | 166.6 |
| A | 4 | 2 | 9974 | 55.05 | 816 | 801 | 166.6 |
| A | 0 | 226 | 7443 | 39.86 | 816 | 801 | 166.6 |
| B | 10 | 16 | 207836 | 1315.33 | 822 | 802 | 157.4 |
| B | 0 | 214 | 50912 | 318.36 | 822 | 802 | 157.4 |
| B | 12 | 111 | 16353 | 98.8 | 822 | 802 | 157.4 |
| C | 13 | 61 | 6082 | 27.89 | 810 | 815 | 188.9 |
| C | 3 | 202 | 2146 | 7.05 | 810 | 815 | 188.9 |
| C | 14 | 67 | 1834 | 5.4 | 810 | 815 | 188.9 |
| D | 2 | 14 | 48009 | 222.89 | 794 | 778 | 211.9 |
| D | 1 | 52 | 40191 | 186.0 | 794 | 778 | 211.9 |
| D | 7 | 71 | 37792 | 174.68 | 794 | 778 | 211.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
