| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_074T01_9000001192_08448cztM0_level2.evt | modeM0/AS1A03_074T01_9000001192_08448cztM0_level2_quad_clean.evt |
| Size (bytes) | 427,337,280 | 92,520,000 |
| Size | 407.5 MB | 88.2 MB |
| Events in quadrant A | 3,089,709 | 575,981 |
| Events in quadrant B | 3,283,979 | 588,423 |
| Events in quadrant C | 3,011,192 | 603,741 |
| Events in quadrant D | 3,109,755 | 575,143 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13771 | 7 |
| B | 0 | 14229 | 6 |
| C | 0 | 13538 | 13 |
| D | 0 | 13916 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6575 | 33 | 0.501901% |
| B | 6575 | 60 | 0.912548% |
| C | 6572 | 22 | 0.334753% |
| D | 6577 | 46 | 0.699407% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7592 | 6578 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7592 | 6578 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7592 | 6578 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7592 | 6578 | 25 | 25 | 0.33% | 0.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 82666 | 516.76 | 774 | 756 | 158.5 |
| A | 15 | 223 | 13337 | 79.37 | 774 | 756 | 158.5 |
| A | 13 | 14 | 11215 | 65.98 | 774 | 756 | 158.5 |
| B | 4 | 81 | 142404 | 945.81 | 784 | 765 | 149.8 |
| B | 10 | 245 | 46304 | 304.09 | 784 | 765 | 149.8 |
| B | 0 | 214 | 43571 | 285.84 | 784 | 765 | 149.8 |
| C | 13 | 61 | 5760 | 27.74 | 770 | 773 | 179.8 |
| C | 12 | 4 | 5514 | 26.37 | 770 | 773 | 179.8 |
| C | 8 | 222 | 2753 | 11.01 | 770 | 773 | 179.8 |
| D | 2 | 152 | 93085 | 470.3 | 756 | 740 | 196.4 |
| D | 7 | 71 | 53132 | 266.82 | 756 | 740 | 196.4 |
| D | 12 | 227 | 31499 | 156.65 | 756 | 740 | 196.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
